Product Description
Built for demanding jobsites, this 2022 Hyundai HX60 excavator demonstrates the durability that construction professionals require. Operating at 6 tons with a working weight of 5,720 kg, this compact machine delivers reliable performance through its Yanmar 4TNV94L engine, producing 36.2 kW of rated power. Currently located in Huizhou, Guangdong, this proven workhorse combines joint venture manufacturing quality with practical engineering.
Engineered for versatility, the HX60 features a 3,000 mm boom and 1,600 mm rod configuration, achieving a maximum digging depth of 3,760 mm and an impressive digging radius of 6,127 mm. The backhoe bucket delivers 46.7 kN of digging force, while the rod provides 27.5 kN, ensuring consistent productivity across varied applications. With a 70% climbing ability and dual-speed travel system (4.6/2.4 km/h), this machine navigates challenging terrain with confidence.
Key specifications include:
- Variable piston pump with 138 l/min maximum flow
- Water-cooled 4-cylinder engine with 3.053L displacement
- Standard hydraulic crushing pipeline for attachment versatility
- Compact transport dimensions: 5,900 mm × 1,920 mm × 2,550 mm
- Comprehensive fluid
| Specifications | Value |
|---|---|
| No. | 994124 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5720 |
| Bucket capacity (m³) | 0.21 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L-ZXSHYB(XSNSRE) |
| Rated power (kw/rpm) | 36.2/2200 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 94 x 110 |
| Maximum torque (N.m) | 201.1/1400 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.053 |
| Working form | 4 stroke, direct injection engine |
| Rotation speed (rpm) | 10.88 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 46.7 |
| Rod digging force (kN) | 27.5 |
| Travel speed (km/h) | 4.6 / 2.4 |
| Rotary hydraulic motor type | Axial piston motor with automatic braking |
| Type of walking hydraulic motor | Two-speed axial plunger motor with brake valve and parking brake |
| Maximum flow of main pump (l/min) | 138 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Variable piston pump |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-80 * 50 * 660 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-85 * 55 * 850 |
| Boom cylinders - Number × diameter × stroke (mm) | 1-105 * 60 * 715 |
| Fuel Tank (L) | 118.5 |
| Hydraulic Tank (L) | 70 |
| Engine Oil changes (L) | 11.6 |
| Coolant (L) | 10 |
| Hydraulic System (L) | 120 |
| Total transport length (mm) | 5900 |
| Total transport width (mm) | 1920 |
| Total transport height (mm) | 2550 |
| Full cab height (mm) | 1860 |
| Minimum turning radius of front working device (mm) | 2350 |
| Back end turning radius (mm) | 1650 |
| Track ground length (mm) | 1990 |
| Number of sprockets (single side) (each) | 1 |
| Number of wheels (single side) (each) | 5 |
| Number of track plates (single side) (PCS) | 40 |
| Maximum digging radius (mm) | 6127 |
| Maximum digging depth (mm) | 3760 |
| Maximum excavation height (mm) | 5753 |
| Maximum unloading height (mm) | 4080 |
| Maximum vertical digging depth (mm) | 2915 |
| Maximum excavation radius of stop surface (mm) | 5990 |
