Product Description
Engineered for precision and operator confidence, this 2021 Hyundai HX75 mini excavator delivers exceptional control in demanding work environments. Powered by a reliable Yanmar 4TNV98-Z engine producing 44.4 kW at 2100 rpm, this 7-ton machine combines robust performance with refined handling characteristics. Operators benefit from enhanced visibility across the 6335mm maximum digging radius, while the 12.5 rpm rotation speed enables smooth, responsive positioning during complex tasks.
Stability remains paramount throughout operation, supported by a 755mm counterweight ground clearance and compact 1730mm rear turning radius. The hydraulic system, featuring a variable piston pump with 158 l/min flow capacity, provides precise bucket and arm control—critical for accurate material placement. With 55.9 kN bucket digging force and 43.9 kN arm digging force, operators can tackle challenging soil conditions while maintaining consistent performance.
- Spacious cabin design optimized for all-day comfort and visibility
- Intuitive controls reduce operator fatigue during extended shifts
- 70% climbing ability handles steep grades with confidence
- Compact dimensions (6080mm length) facilitate transport
| Specifications | Value |
|---|---|
| No. | 996002 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7000 |
| Bucket capacity (m³) | 0.32 |
| Boom length (mm) | 3700 |
| Rod length (mm) | 1670 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV98-Z |
| Rated power (kw/rpm) | 44.4/2100 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 98 x 110 |
| Number of cylinders (PCS) | 4 |
| Rotation speed (rpm) | 12.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 55.9 |
| Rod digging force (kN) | 43.9 |
| Travel speed (km/h) | 4.0/2.4 |
| Maximum flow of main pump (l/min) | 158 |
| Main pump type | Variable piston pump |
| Fuel Tank (L) | 140 |
| Hydraulic Tank (L) | 130 |
| Engine Oil changes (L) | 9.2 |
| Coolant (L) | 11 |
| Hydraulic System (L) | 75 |
| Total transport length (mm) | 6080 |
| Total transport width (mm) | 2260 |
| Total transport height (mm) | 2550 |
| Counterweight ground clearance (mm) | 755 |
| Minimum turning radius of front working device (mm) | 1750 |
| Back end turning radius (mm) | 1730 |
| Number of sprockets (single side) (each) | 1 |
| Number of wheels (single side) (each) | 5 |
| Number of track plates (single side) (PCS) | 38 |
| Maximum digging radius (mm) | 6335 |
| Maximum digging depth (mm) | 4015 |
| Maximum excavation height (mm) | 7175 |
| Maximum unloading height (mm) | 5080 |
| Maximum vertical digging depth (mm) | 3120 |
| Maximum excavation radius of stop surface (mm) | 6185 |
