Product Description
Ready to ship from Guangxi, China — this 2020 Hyundai R110-7 mini excavator puts 11 tons of proven digging performance in your hands without the factory wait. Skip the lead times and get a machine that's available now, fully inspected and ready for fast deployment to your site.
Powered by a Mitsubishi S4K-T four-cylinder, four-stroke turbocharged diesel engine producing 70 kW at 1,950 RPM, this 11,200 kg machine delivers serious output for its class. With a maximum digging depth of 5,090 mm, a digging radius of 7,740 mm, and a bucket digging force of 78.5 kN, the R110-7 handles foundation work, utility trenching, and site preparation with no compromise.
- Engine: Mitsubishi S4K-T | 70 kW / 1,950 RPM | Water-cooled
- Operating Weight: 11,200 kg | Bucket Capacity: 0.30–0.59 m³
- Max Digging Depth: 5,090 mm | Max Digging Radius: 7,740 mm
- Bucket Digging Force: 78.5 kN | Arm Digging Force: 55.7 kN
- Travel Speed: 3.4–5.5 km/h | Gradeability: 70% / 35°
- Hydraulic System: 2× Variable Axial Piston Pumps | 2 × 112 L/min
- Fuel Tank: 250 L | Transport Dimensions: 7,270 × 2,490 × 2,800 mm
- Location: Guangxi, China — positioned for efficient export across Southeast Asia and beyond
Sourced from a joint venture manufacturer and built to import-grade standards, this unit is priced to move. Contact us today to confirm availability and arrange logistics from Guangxi to your port of choice.
| Specifications | Value |
|---|---|
| No. | 1086526 |
| Tonnage (tons) | 11 |
| Working weight (kg) | 11200 |
| Bucket capacity (m³) | 0.30-0.59 |
| Boom length (mm) | 4300 |
| Rod length (mm) | 2260 |
| Country of origin | Peking |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi S4K-T |
| Rated power (kw/rpm) | 70/1950 |
| Cooling mode | water-cooling |
| Maximum torque (N.m/rpm) | 371.4 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.2 |
| Working form | Four-cylinder, four-stroke turbocharged direct injection diesel engine |
| Rotation speed (rpm) | 13 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 78.5 |
| Rod digging force (kN) | 55.7 |
| Travel speed (km/h) | 3.4-5.5 |
| Rotary hydraulic motor type | Quantitative swash plate plunger motor |
| Type of walking hydraulic motor | Variable swash plate plunger motor |
| Maximum flow of main pump (l/min) | 2 x 112 |
| Traveling Hydraulic Circuit (Mpa) | 33 |
| Rotary Hydraulic Circuit (Mpa) | 24 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | 2× variable axial piston pump |
| Working Hydraulic Circuit (Mpa) | 33 |
| Pilot Oil Circuit (MPa) | 3.5 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 100 |
| Engine Oil changes (L) | 17.5 |
| Total transport length (mm) | 7270 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2800 |
| Full cab height (mm) | 2800 |
| Counterweight ground clearance (mm) | 900 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 2380 |
| Back end turning radius (mm) | 2130 |
| Onboard width (mm) | 2800 |
| Total track length (mm) | 3340 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2490 |
| Track ground length (mm) | 2610 |
| Maximum digging radius (mm) | 7740 |
| Maximum digging depth (mm) | 5090 |
| Maximum excavation height (mm) | 8070 |
| Maximum unloading height (mm) | 5710 |
| Maximum vertical digging depth (mm) | 4430 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
| Maximum excavation radius of stop surface (mm) | 7610 |
| Maximum effective digging depth (mm) | 4870 |
