Product Description
Backed by Hyundai's proven engineering legacy, this 2016 R150W-9 wheeled excavator delivers dependable performance for contractors seeking reliable used equipment. Operating at 15 tons with a robust Cummins B5.9-C engine producing 112kW at 1950rpm, this machine combines power with proven durability. The six-cylinder turbocharged powerplant generates 613.48 N.m of maximum torque, while hydraulic systems featuring dual variable swash plate piston pumps (2 x 168 l/min) ensure consistent operation across demanding jobsites.
Currently located in Guilin, Guangxi, this unit offers significant advantages in the used market:
- Extensive parts network throughout China ensures minimal downtime and cost-effective maintenance
- Cummins engine components readily available through established distribution channels
- Strong resale value retention due to Hyundai's reputation for longevity
- Comprehensive specifications: 7920mm maximum digging radius, 4850mm digging depth, 101.9kN bucket force
- Versatile bucket capacity range (0.23-0.71m³) adapts to multiple applications
With 37km/h travel speed and 35% climbing ability, this R150W-9 maintains productivity while offering the financial se
| Specifications | Value |
|---|---|
| No. | 996102 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 13700 |
| Bucket capacity (m³) | 0.23-0.71 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2100 |
| Country of origin | Peking |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Cummins B5.9-C |
| Rated power (kw/rpm) | 112/1950 |
| Total displacement (L) | 5.9 |
| Cooling mode | water-cooling |
| remark | Six-cylinder four-stroke turbocharged direct injection engine |
| Maximum torque (N.m) | 613.48 |
| Number of cylinders (PCS) | 6 |
| Forward speed (Km/h) | 37 |
| Rotation speed (rpm) | 13 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 101.9 |
| Rod digging force (kN) | 65.6 |
| Maximum tractive force (kN) | 83.3 |
| Driving form | Hydraulic motor |
| Main overflow set pressure (Mpa) | 350 |
| Rotary hydraulic motor type | Variable swash plate plunger motor |
| Maximum flow of main pump (l/min) | 2 x 168 |
| Main pump type | Variable swash plate piston pump |
| Working Hydraulic Circuit (Mpa) | Quantitative swash plate plunger motor |
| Fuel Tank (L) | 270 |
| Hydraulic Tank (L) | 126 |
| Total transport length (mm) | 7760 |
| Total transport width (mm) | 2500 |
| Total transport height (mm) | 3500 |
| Full cab height (mm) | 3137 |
| Counterweight ground clearance (mm) | 1233 |
| Wheelbase (mm) | 2800 |
| Single tire width (mm) | 900×20-14PR |
| Total tire outside width (mm) | 2495 |
| Wheel base (mm) | 1944 |
| Minimum ground clearance (mm) | 365 |
| Onboard width (mm) | 2500 |
| Maximum digging radius (mm) | 7920 |
| Maximum excavation radius (mm) | 7700 |
| Maximum digging depth (mm) | 4850 |
| Maximum excavation height (mm) | 8470 |
| Maximum unloading height (mm) | 6040 |
| Maximum vertical digging depth (mm) | 4460 |
| Minimum turning radius (mm) | 2670 |
| Dodging plate width × height (mm) | 2490 x 559 |
