Product Description
Built for demanding construction and excavation work, this 2019 Hyundai R150W-9 wheeled excavator delivers reliable performance with its robust 15-ton capacity and Cummins B5.9-C engine producing 112kW of power. Equipped with a versatile bucket system ranging from 0.23 to 0.71 m³ capacity, this machine handles everything from precision digging to heavy material loading with exceptional efficiency.
Key operational advantages include:
- Maximum digging depth of 4,850mm and reach of 7,920mm for extensive work coverage
- Powerful digging forces: 101.9kN bucket force and 65.6kN rod force for tough soil conditions
- Mobile design with 37km/h road speed and 2,670mm turning radius for quick site positioning
- Dual hydraulic pumps (2 x 168 l/min) ensuring smooth, responsive operation
- 270L fuel capacity minimizing downtime during extended work shifts
Currently located in Zhejiang Shaoxing, this joint venture machine combines proven Hyundai engineering with immediate availability for grading, trenching, and demolition projects requiring precision and power.
| Specifications | Value |
|---|---|
| No. | 992995 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 13700 |
| Bucket capacity (m³) | 0.23-0.71 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2100 |
| Country of origin | Peking |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Cummins B5.9-C |
| Rated power (kw/rpm) | 112/1950 |
| Total displacement (L) | 5.9 |
| Cooling mode | water-cooling |
| remark | Six-cylinder four-stroke turbocharged direct injection engine |
| Maximum torque (N.m) | 613.48 |
| Number of cylinders (PCS) | 6 |
| Forward speed (Km/h) | 37 |
| Rotation speed (rpm) | 13 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 101.9 |
| Rod digging force (kN) | 65.6 |
| Maximum tractive force (kN) | 83.3 |
| Driving form | Hydraulic motor |
| Main overflow set pressure (Mpa) | 350 |
| Rotary hydraulic motor type | Variable swash plate plunger motor |
| Maximum flow of main pump (l/min) | 2 x 168 |
| Main pump type | Variable swash plate piston pump |
| Working Hydraulic Circuit (Mpa) | Quantitative swash plate plunger motor |
| Fuel Tank (L) | 270 |
| Hydraulic Tank (L) | 126 |
| Total transport length (mm) | 7760 |
| Total transport width (mm) | 2500 |
| Total transport height (mm) | 3500 |
| Full cab height (mm) | 3137 |
| Counterweight ground clearance (mm) | 1233 |
| Wheelbase (mm) | 2800 |
| Single tire width (mm) | 900×20-14PR |
| Total tire outside width (mm) | 2495 |
| Wheel base (mm) | 1944 |
| Minimum ground clearance (mm) | 365 |
| Onboard width (mm) | 2500 |
| Maximum digging radius (mm) | 7920 |
| Maximum excavation radius (mm) | 7700 |
| Maximum digging depth (mm) | 4850 |
| Maximum excavation height (mm) | 8470 |
| Maximum unloading height (mm) | 6040 |
| Maximum vertical digging depth (mm) | 4460 |
| Minimum turning radius (mm) | 2670 |
| Dodging plate width × height (mm) | 2490 x 559 |
