Product Description
Discover the reliability and efficiency of the 2020 Hyundai R150WVS, a robust wheel excavator, now available in Chongqing, China. This model, known for its versatility and durability, was one of the last to feature the distinctive yellow arm, making it a standout choice for your construction fleet. The machine's condition is exceptional, having been meticulously maintained, ensuring it is ready to tackle any job site without delay. Ideal for a variety of applications, from excavation to loading, this R150WVS is a solid investment for businesses looking to enhance their operational capabilities with a trusted and well-preserved piece of equipment.
- Year: 2020
- Brand: Hyundai
- Model: R150WVS
- Location: Chongqing, China
- Condition: Excellent, ready for immediate use
| Specifications | Value |
|---|---|
| No. | 1130212 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 13700 |
| Bucket capacity (m³) | 0.58 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2100 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Hyundai HE6.7 |
| Rated power (kw/rpm) | 108/2200 |
| Total displacement (L) | 6.7 |
| Cooling mode | water-cooling |
| remark | 4 stroke, turbocharged |
| Cylinder diameter × stroke (mm) | 107 x 124 |
| Number of cylinders (PCS) | 6 |
| Forward speed (Km/h) | 10-37 |
| Rotation speed (rpm) | 11.6 |
| Climbing ability (%) | 70 (35°) |
| Minimum turning radius (m) | 6.3 |
| Maximum tractive force (kN) | 83.4 |
| Maximum flow of main pump (l/min) | 2 x 127 |
| Traveling Hydraulic Circuit (Mpa) | 38 |
| Rotary Hydraulic Circuit (Mpa) | 28.5 |
| Boom cylinder - Cylinder diameter × stroke (mm) | 2 - ø 105 x ø 75 x 1615 |
| Bucket rod cylinder - Cylinder diameter × stroke (mm) | 1 - ø 115 x ø 80 x 1668 |
| Bucket cylinder - Cylinder diameter × stroke (mm) | 1 - ø 100 x ø 70 x 1345 |
| Main pump type | Two variable plunger pump |
| Working Hydraulic Circuit (Mpa) | 35 |
| Fuel Tank (L) | 270 |
| Hydraulic Tank (L) | 124 |
| Engine Oil changes (L) | 23.7 |
| Coolant (L) | 19.5 |
| Hydraulic System (L) | 210 |
| Total transport length (mm) | 7820 |
| Total transport width (mm) | 2500 |
| Total transport height (mm) | 3140 |
| Maximum digging radius (mm) | 7920 |
| Maximum excavation radius (mm) | 7700 |
| Maximum digging depth (mm) | 4850 |
| Maximum excavation height (mm) | 8470 |
| Maximum unloading height (mm) | 6040 |
| Maximum vertical digging depth (mm) | 4460 |
| Minimum turning radius (mm) | 2670 |
