Product Description
Built in 2016, this Hyundai R305LC-7 delivers proven performance with the backing of a globally recognized brand. Operating at 30 tons with a robust 29,400 kg working weight, this crawler excavator combines a Cummins C8.3-C engine (190 kW at 1900 rpm) with dual variable axial piston pumps for consistent hydraulic power. Maximum digging reach extends to 10,820 mm, while bucket digging force hits 192.2 kN—ideal for heavy earthmoving and site preparation.
Hyundai's reputation in the used equipment market stems from widespread parts availability and strong resale retention. Joint venture manufacturing standards ensure quality components, from the 1.38 m³ backhoe bucket to the water-cooled 8.27 L displacement engine. With a 6,250 mm boom and 3,050 mm arm configuration, this machine balances reach and breakout force across demanding applications.
Key specifications include:
- Bucket digging force: 192.2 kN / Arm force: 128.5 kN
- Maximum digging depth: 7,500 mm
- Travel speed: 3.1–5.2 km/h with 70% gradeability
- Fuel capacity: 480 L / Hydraulic tank: 210 L
- Transport dimensions: 10,560 × 3,200 × 3,290 mm
Currently located in Jincheng, Shanxi. Contact Fair Trade Machin
| Specifications | Value |
|---|---|
| No. | 1048841 |
| Tonnage (tons) | 30 |
| Working weight (kg) | 29400 |
| Bucket capacity (m³) | 1.38 |
| Boom length (mm) | 6250 |
| Rod length (mm) | 3050 |
| Country of origin | Jiangsu (Province) |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Cummins C8.3-C |
| Rated power (kw/rpm) | 190/1900 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 114 x 135 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 8.27 |
| Ground specific pressure (Kpa) | 56 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 192.2 |
| Rod digging force (kN) | 128.5 |
| Travel speed (km/h) | 3.1-5.2 |
| Maximum flow of main pump (l/min) | 2 x 260 |
| Traveling Hydraulic Circuit (Mpa) | 330 |
| Rotary Hydraulic Circuit (Mpa) | 265 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | 2× variable axial piston pump + gear pump |
| Working Hydraulic Circuit (Mpa) | 330 |
| Pilot Oil Circuit (MPa) | 35 |
| Bucket cylinders - Number × diameter × stroke (mm) | 140 * 95 * 1185 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 150 * 110 * 1765 |
| Boom cylinders - Number × diameter × stroke (mm) | 140 * 100 * 1465 |
| Fuel Tank (L) | 480 |
| Hydraulic Tank (L) | 210 |
| Engine Oil changes (L) | 19 |
| Coolant (L) | 50 |
| Hydraulic System (L) | 320 |
| Total transport length (mm) | 10560 |
| Total transport width (mm) | 3200 |
| Total transport height (mm) | 3290 |
| Full cab height (mm) | 3010 |
| Counterweight ground clearance (mm) | 1190 |
| Minimum ground clearance (mm) | 500 |
| Back end turning radius (mm) | 3200 |
| Total track length (mm) | 4940 |
| Track gauge (mm) | 2600 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3200 |
| Track ground length (mm) | 4030 |
| Maximum digging radius (mm) | 10820 |
| Maximum digging depth (mm) | 7500 |
| Maximum excavation height (mm) | 10160 |
| Maximum unloading height (mm) | 7110 |
| Maximum vertical digging depth (mm) | 6410 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
| Maximum excavation radius of stop surface (mm) | 10620 |
| Maximum effective digging depth (mm) | 7300 |
