Product Description
Engineered for demanding excavation work, this 2016 Hyundai R335LC-9T delivers exceptional operator control and jobsite performance. Powered by a robust Cummins C8.3-C engine generating 196 kW at 1900 rpm, this 33-ton excavator combines raw power with precise hydraulic responsiveness. The dual variable axial piston pumps provide 2 × 270 l/min flow capacity, ensuring smooth simultaneous operations and reduced cycle times.
Operator comfort and visibility define the working experience in this machine. The spacious cab sits 3090mm high, offering commanding sightlines across the 11,140mm maximum digging radius. Intuitive controls respond to a sophisticated hydraulic system operating at 34.3 MPa, delivering 212 kN bucket digging force and 147 kN arm digging force. Stability remains uncompromised with a 4030mm track ground length and 2680mm track gauge, while the 63 kPa ground pressure minimizes surface disturbance.
- Heavy-duty 6450mm boom with extended 4050mm arm option
- 1.44 m³ bucket capacity for high-volume material handling
- 9.2 rpm rotation speed with 70% climbing capability
- Standard hydraulic crushing pipeline for attachment versatility
- Currently located in Guizhou, ready for de
| Specifications | Value |
|---|---|
| No. | 996303 |
| Tonnage (tons) | 33 |
| Working weight (kg) | 32200 |
| Bucket capacity (m³) | 1.44 |
| Boom length (mm) | Heavy duty 6450 |
| Rod length (mm) | Overloading 2500/ Lengthening 4050 |
| Country of origin | Jiangsu (Province) |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Cummins C8.3-C |
| Rated power (kw/rpm) | 196/1900 |
| Cooling mode | water-cooling |
| Maximum torque (N.m/rpm) | 1218.1 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 8.3 |
| Working form | Six-cylinder, four-stroke, turbocharged intercooled direct injection engine |
| Ground specific pressure (Kpa) | 63 |
| Rotation speed (rpm) | 9.2 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 212 |
| Rod digging force (kN) | 147 |
| Maximum tractive force (kN) | 295 |
| Travel speed (km/h) | 5.5/3.3 |
| Main overflow set pressure (Mpa) | 38 |
| Rotary hydraulic motor type | Quantitative swash plate axial piston pump |
| Type of walking hydraulic motor | Variable swash plate axial piston pump |
| Maximum flow of main pump (l/min) | 2 x 270 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 30 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | 2× variable axial piston pump |
| Working Hydraulic Circuit (Mpa) | 34.3 |
| Pilot Oil Circuit (MPa) | 4 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1 x 140 x 1285 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1 x 160 x 1685 |
| Boom cylinders - Number × diameter × stroke (mm) | 2 x 150 x 1480 |
| Fuel Tank (L) | 500 |
| Hydraulic Tank (L) | 190 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 55 |
| Hydraulic System (L) | 330 |
| Total transport length (mm) | 10980 |
| Total transport width (mm) | 3280 |
| Total transport height (mm) | 3380 |
| Full cab height (mm) | 3090 |
| Counterweight ground clearance (mm) | 1200 |
| Minimum ground clearance (mm) | 500 |
| Minimum turning radius of front working device (mm) | 4470 |
| Back end turning radius (mm) | 3330 |
| Onboard width (mm) | 2980 |
| Total track length (mm) | 4940 |
| Track gauge (mm) | 2680 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3280 |
| Track ground length (mm) | 4030 |
| Maximum digging radius (mm) | 11140 |
| Maximum digging depth (mm) | 7370 |
| Maximum excavation height (mm) | 10310 |
| Maximum unloading height (mm) | 7240 |
| Maximum vertical digging depth (mm) | 6360 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
| Maximum excavation radius of stop surface (mm) | 10940 |
| Boom turning Angle (left/right °) | There is no |
| Maximum effective digging depth (mm) | 7210 |
