Product Description
Built for heavy production work, this 2018 Hyundai R350LVS excavator delivers 35-ton performance across demolition, deep excavation, and mass grading applications. Powered by a Hyundai HE8.9 engine producing 221kW at 1850rpm, this machine combines a 10,920mm maximum digging reach with 6,970mm depth capability to handle large-scale earthmoving projects with precision. Currently located in Shanghai, this crawler excavator arrives site-ready with proven joint venture engineering and water-cooled reliability.
- Operating weight: 33,200kg with 1.60m³ backhoe bucket capacity
- Dual variable plunger pumps supplying 2×315 L/min hydraulic flow for responsive cycle times
- 6,450mm boom and 2,850mm arm configuration optimized for truck loading and trench work
- 70% grading ability with 6.3/3.5 km/h travel speeds for efficient repositioning
- 10,540mm maximum excavation height reaches second-story demolition zones
- 560L fuel tank and 330L hydraulic system capacity support extended shift operations
Spec'd for contractors requiring consistent output on infrastructure, mining, or commercial development sites, this R350LVS provides the reach, power, and stability necessary for demanding
| Specifications | Value |
|---|---|
| No. | 1019844 |
| Tonnage (tons) | 35 |
| Working weight (kg) | 33200 |
| Bucket capacity (m³) | 1.60 |
| Boom length (mm) | 6450 |
| Rod length (mm) | 2850 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | HYUNDAI HE8.9 |
| Rated power (kw/rpm) | 221 / 1850 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 114 x 145 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 8.9 |
| Rotation speed (rpm) | 9.8 |
| Climbing ability (%) | 70 |
| Travel speed (km/h) | 6.3/3.5 |
| Type of walking hydraulic motor | Axial piston motor |
| Maximum flow of main pump (l/min) | 2 x 315 |
| Main pump type | Two variable plunger pump |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-140 x 100 x 1285 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-160 x 110 x 1685 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-150 x 105 x 1480 |
| Fuel Tank (L) | 560 |
| Hydraulic Tank (L) | 190 |
| Engine Oil changes (L) | 31.7 |
| Coolant (L) | 50 |
| Hydraulic System (L) | 330 |
| Total transport length (mm) | 10990 |
| Total transport width (mm) | 3280 |
| Total transport height (mm) | 3460 |
| Full cab height (mm) | 3090 |
| Counterweight ground clearance (mm) | 1200 |
| Minimum turning radius of front working device (mm) | 4520 |
| Back end turning radius (mm) | 3330 |
| Onboard width (mm) | 3265 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 48 |
| Maximum digging radius (mm) | 10920 |
| Maximum digging depth (mm) | 6970 |
| Maximum excavation height (mm) | 10540 |
| Maximum unloading height (mm) | 7380 |
| Maximum vertical digging depth (mm) | 6270 |
| Maximum excavation radius of stop surface (mm) | 10710 |
| Maximum effective digging depth (mm) | 6800 |
