Product Description
Built to endure the toughest conditions, this 2011 Hyundai R385LVS excavator represents over a decade of proven performance in demanding environments. Operating at 38 tons with a robust 221kw HYUNDAI HE8.9 engine, this machine delivers consistent power and reliability that has stood the test of time. Currently located in Guizhou, this workhorse combines substantial digging capabilities with the durability expected from joint venture engineering.
Engineered for heavy-duty applications, the R385LVS features a 1.9m³ bucket capacity and impressive reach specifications: 10,520mm maximum digging radius and 6,750mm maximum digging depth. The dual variable plunger pump system provides 2×315 l/min flow capacity, ensuring responsive hydraulic performance across all functions. Water-cooled 8.9L displacement engine with 6 cylinders maintains optimal operating temperatures during extended work cycles.
- 38-ton operating weight with proven track record since 2011
- 221kw rated power at 1850 rpm for consistent productivity
- 10,520mm maximum digging radius for extensive work envelope
- 70% climbing ability tackles challenging terrain
- 610L fuel capacity minimizes refueling downtime
- Traditio
| Specifications | Value |
|---|---|
| No. | 1010655 |
| Tonnage (tons) | 38 |
| Working weight (kg) | 38,900 |
| Bucket capacity (m³) | 1.9 |
| Boom length (mm) | 6150 |
| Rod length (mm) | 2800 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | HYUNDAI HE8.9 |
| Rated power (kw/rpm) | 221/1850 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 114*145 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 8.9 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 70 |
| Travel speed (km/h) | 5.0 / 3.2 |
| Maximum flow of main pump (l/min) | 2*315 |
| Main pump type | Two variable plunger pump |
| Bucket cylinders - Number × diameter × stroke (mm) | 1*150*105*1295 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1*170*120*1760 |
| Boom cylinders - Number × diameter × stroke (mm) | 2*160*110*1500 |
| Pilot pump type | Gear pump |
| Fuel Tank (L) | 610 |
| Hydraulic Tank (L) | 210 |
| Engine Oil changes (L) | 31.7 |
| Coolant (L) | 50 |
| Hydraulic System (L) | 415 |
| Total transport length (mm) | 10830 |
| Total transport width (mm) | 3340 |
| Total transport height (mm) | 3680 |
| Counterweight ground clearance (mm) | 1290 |
| Minimum turning radius of front working device (mm) | 4220 |
| Back end turning radius (mm) | 3415 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 51 |
| Maximum digging radius (mm) | 10520 |
| Maximum digging depth (mm) | 6750 |
| Maximum excavation height (mm) | 10150 |
| Maximum unloading height (mm) | 7030 |
| Maximum vertical digging depth (mm) | 4480 |
| Maximum excavation radius of stop surface (mm) | 10290 |
| Maximum effective digging depth (mm) | 6580 |
