Product Description
Maximize your excavation budget with this 2018 Hyundai R385LVS crawler excavator—a proven 38-ton workhorse delivering premium performance without the premium price tag. Powered by a robust HYUNDAI HE8.9 engine generating 221kW at 1850rpm, this machine combines reliability with exceptional productivity. Currently located in Maoming, Guangdong, it offers an intelligent alternative to costly new equipment purchases.
Performance specifications include:
- Operating weight: 38,900 kg with 1.9 m³ bucket capacity
- Impressive reach: 10,520mm maximum digging radius and 6,750mm digging depth
- Dual variable plunger pumps delivering 2×315 L/min hydraulic flow
- Water-cooled 8.9L displacement engine for sustained heavy-duty operation
- 70% climbing ability and 9.5 rpm rotation speed for versatile job site maneuverability
Investing in quality used equipment means accessing joint venture/import-grade construction machinery at a fraction of new market prices. This R385LVS provides the digging power, hydraulic efficiency, and operational capacity your projects demand—backed by Hyundai's engineering reputation. Smart contractors recognize that strategic equipment acquisition directly impa
| Specifications | Value |
|---|---|
| No. | 1027844 |
| Tonnage (tons) | 38 |
| Working weight (kg) | 38,900 |
| Bucket capacity (m³) | 1.9 |
| Boom length (mm) | 6150 |
| Rod length (mm) | 2800 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | HYUNDAI HE8.9 |
| Rated power (kw/rpm) | 221/1850 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 114*145 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 8.9 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 70 |
| Travel speed (km/h) | 5.0 / 3.2 |
| Maximum flow of main pump (l/min) | 2*315 |
| Main pump type | Two variable plunger pump |
| Bucket cylinders - Number × diameter × stroke (mm) | 1*150*105*1295 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1*170*120*1760 |
| Boom cylinders - Number × diameter × stroke (mm) | 2*160*110*1500 |
| Pilot pump type | Gear pump |
| Fuel Tank (L) | 610 |
| Hydraulic Tank (L) | 210 |
| Engine Oil changes (L) | 31.7 |
| Coolant (L) | 50 |
| Hydraulic System (L) | 415 |
| Total transport length (mm) | 10830 |
| Total transport width (mm) | 3340 |
| Total transport height (mm) | 3680 |
| Counterweight ground clearance (mm) | 1290 |
| Minimum turning radius of front working device (mm) | 4220 |
| Back end turning radius (mm) | 3415 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 51 |
| Maximum digging radius (mm) | 10520 |
| Maximum digging depth (mm) | 6750 |
| Maximum excavation height (mm) | 10150 |
| Maximum unloading height (mm) | 7030 |
| Maximum vertical digging depth (mm) | 4480 |
| Maximum excavation radius of stop surface (mm) | 10290 |
| Maximum effective digging depth (mm) | 6580 |
