Name: Used Excavators 2019 Hyundai R485LVS
Brand: Hyundai
SKU: USED-1035572
Availability: InStock
Rating: 4.7 (25 reviews)

Sany

Caterpillar

XCMG

Hitachi

Komatsu

Doosan

Kobelco

Hyundai

Volvo

Sumitomo

Kato

Case

Yanmar

JohnDeere

Liebherr

Built for operators who demand precision and control, the 2019 Hyundai R485LVS is a 48-ton class excavator engineered to perform across the most demanding large-scale earthmoving operations. Powered by a Cummins QSM11 6-cylinder, 10.8L water-cooled engine producing 266 kW at 1,900 RPM, this machine delivers consistent hydraulic output through dual variable plunger pumps with a maximum combined flow of 740 L/min — keeping cycle times tight and productivity high throughout every shift.

From the operator's seat, the R485LVS is designed for confidence. The spacious, low-vibration cab provides commanding sightlines across a maximum digging radius of 11,040 mm and an excavation depth of 6,860 mm. Ergonomic controls reduce fatigue during long working days, while the axial plunger rotary motor with automatic control ensures smooth, responsive swing performance.

<ul>
 <li>Operating weight: 48,400 kg | Bucket capacity: 2.2 m³</li>
 <li>Maximum digging depth: 6,860 mm | Maximum reach: 11,040 mm</li>
 <li>Climbing ability: 70% | Travel speed: 4.7 / 2.9 km/h</li>
 <li>Fuel tank: 620 L | Hydraulic system: 380 L</li>
 <li>Track plate width: 600 mm | Transport dimensions: 11,650 × 3,340 × 3,870 mm</li>
 <li>Currently located in L

Built for demanding jobsites, this 2013 Caterpillar 323DL delivers proven performance with its robust 23-ton operating weight and powerful C6.4 ACERT engine generating 110kW at 2000 RPM. Located in Guangdong Maoming, this Japanese-manufactured machine combines reliability with impressive digging capabilities.

Key operational specifications include:
<ul>
<li>Maximum digging depth of 6.71m and excavation height of 9.47m</li>
<li>1.2m³ bucket capacity with 140kN digging force</li>
<li>9.85m maximum excavation radius for extended reach applications</li>
<li>Dual travel speeds (3.5/5.7 km/h) for efficient site mobility</li>
<li>410L fuel capacity supporting extended operating periods</li>
</ul>

Equipped with water-cooled 6-cylinder engine and comprehensive hydraulic system featuring 205 L/min main pump flow, this excavator handles grading, trenching, and demolition tasks with precision. The 5.7m boom and 2.9m arm configuration provides optimal working geometry for construction and earthmoving operations. Ready for immediate deployment with standard hydraulic connections and proven Caterpillar engineering.

Caterpillar 323DL

Maximize your construction budget with this proven 2006 Hitachi ZAXIS200 excavator, delivering 20-ton performance at a fraction of new equipment costs. Located in Shandong Dongying, this joint venture machine combines reliable traditional power with impressive operational specifications.

Built for serious earthmoving operations, this excavator features a robust 103kW engine generating maximum power at 1900 RPM. The 0.8m³ bucket capacity and 9.91m maximum digging radius handle substantial material volumes efficiently, while the 6.48m maximum digging depth tackles deep excavation projects with confidence.

<ul>
<li>Working weight: 21,700kg for exceptional stability</li>
<li>Low ground pressure: 49 KPa minimizes surface damage</li>
<li>600mm track plates ensure superior traction</li>
<li>Maximum unloading height: 6.97m for truck loading versatility</li>
</ul>

Smart contractors recognize the value proposition: proven Hitachi engineering reliability without the premium price tag. This machine offers decades of productive service ahead while preserving capital for other critical investments. Ready for immediate deployment on your next project.

Hitachi ZAXIS200

Ready for immediate deployment, this 2020 Sany SY75 compact excavator delivers reliable 7-ton performance for demanding construction and utility projects. Built with traditional power systems and proven Chinese manufacturing standards, this machine handles digging, grading, and demolition tasks with consistent precision.

Key operational capabilities include:
<ul>
<li>7-ton lifting capacity for medium-scale earthmoving operations</li>
<li>Backhoe bucket configuration optimized for trenching and excavation</li>
<li>Traditional power system ensuring straightforward maintenance protocols</li>
<li>Compact footprint suitable for confined work areas and urban jobsites</li>
</ul>

Currently positioned in Wenzhou, Zhejiang Province, this SY75 represents proven Sany engineering at an accessible price point. With four years of field-tested reliability, the machine stands ready to integrate into your fleet operations without delay. Ideal for contractors requiring dependable excavation capacity for foundation work, utility installation, and site preparation projects.

Sany SY75

From 浙江温州, this 2016 XCMG LW500F loader is available now, ready to enhance your logistics and speed. With a rated power of 162 kW, it offers robust performance for demanding tasks. The machine, equipped with a bucket capacity ranging from 2.5 to 4.5 m³, can handle a rated load of 5000 kg. Its digging force of 170 kN ensures efficient material handling. Operating at a weight of 16900 kg, the LW500F boasts a maximum unloading height of 3150 to 3560 mm and an unloading distance of 1274 mm. Skip the factory lead times and deploy this powerful loader to your site swiftly. Ideal for quick turnaround and high productivity, the LW500F is a reliable choice for your heavy machinery needs.

XCMG LW500F

Engineered for demanding excavation work, this 2016 Sany SY365C delivers robust 36-ton performance through proven hydraulic architecture and reliable traditional power systems. Manufactured in China to Sany's industrial-grade specifications, this mid-size excavator combines responsive hydraulic flow control with efficient engine management, ensuring consistent productivity across trenching, loading, and site preparation applications.

Key technical specifications include:
<ul>
<li>Operating weight: 36 tons for optimal stability and reach</li>
<li>Traditional diesel powertrain with dependable fuel efficiency</li>
<li>Factory-equipped backhoe bucket configuration</li>
<li>Advanced hydraulic system engineered for precise control</li>
<li>Sany SY365C series construction quality and component durability</li>
<li>Currently located in Shenzhen, Guangdong, China</li>
</ul>

Built on Sany's established C-series platform, this model represents mature engineering with field-proven reliability. The SY365C's hydraulic system provides proportional control across all functions, while the traditional power unit offers straightforward maintenance and global parts availability. Suitable for contractors requiring dependable mid-range exc

Sany SY365C

Engineered for maximum productivity in heavy-duty excavation, this 2014 Caterpillar 374D delivers 70 tons of operational power through advanced hydraulic systems and proven diesel performance. Built as a joint venture/import model, the machine integrates Caterpillar's renowned engineering standards with precision manufacturing protocols that ensure consistent performance across demanding job sites.

Hydraulic flow rates and boom breakout forces on the 374D exceed industry benchmarks for the 70-ton class, while the traditional power configuration provides reliable fuel efficiency and simplified maintenance access. The backhoe attachment handles deep excavation tasks with controlled precision, supported by reinforced structural components designed for extended service intervals.

<ul>
<li>70-ton operating weight for stability in large-scale earthmoving</li>
<li>Advanced hydraulic architecture with responsive control systems</li>
<li>Traditional power plant engineered for durability and torque</li>
<li>Backhoe configuration optimized for trenching and foundation work</li>
<li>Currently located in Wenzhou, Zhejiang—ready for global deployment</li>
</ul>

This unit represents Caterpillar's commitment to heavy excavator perf

Caterpillar 374D

Engineered for demanding excavation operations, this 2018 Sany SY125C delivers exceptional performance through precision hydraulics and robust powertrain integration. At its core sits the Isuzu 4JJ1-XDJAG-01-C3 engine, generating 73kW at 2000 rpm with 365 N·m maximum torque, providing consistent power delivery across varied jobsite conditions. Operating at 12 tons working weight with 0.55 m³ bucket capacity, this crawler excavator combines impressive digging force—90.6 kN bucket force and 57.2 kN arm force—with a maximum reach of 7,735 mm and digging depth of 5,190 mm.

<ul>
<li>Isuzu water-cooled diesel engine with 2.999L displacement for reliable performance</li>
<li>Advanced hydraulic system supporting 13.06 rpm rotation speed and 70% grading capability</li>
<li>Optimized dimensions: 7,280 mm transport length, 2,550 mm width, 425 mm ground clearance</li>
<li>Large capacity tanks: 240L fuel, 150L hydraulic oil for extended operation</li>
<li>41.6 kPa ground pressure minimizing surface disturbance</li>
<li>Currently located in Hangzhou, Zhejiang—ready for international shipment</li>
</ul>

Built to Chinese manufacturing standards, this machine represents proven Sany engineering quality with comprehensive technical documentat

Sany SY125C

Positioned in 浙江温州 and ready for immediate deployment, this 2019 Caterpillar 349E excavator eliminates costly factory lead times. With a robust 49-ton operating weight and proven traditional power system, this joint venture-manufactured machine delivers the reliability Caterpillar is known for across demanding earthmoving applications. Skip months of waiting—secure a field-proven excavator that's available now for fast shipment to your job site.

<ul>
<li>Year: 2019</li>
<li>Operating Weight: 49 tons</li>
<li>Power Type: Traditional diesel power</li>
<li>Configuration: Backhoe</li>
<li>Manufacturer: Joint venture/Import</li>
<li>Current Location: 浙江温州, China</li>
<li>Availability: In stock—immediate purchase and deployment</li>
</ul>

Reduce project delays with equipment that's inspection-ready and available for rapid mobilization. Contact Fair Trade Machinery today to arrange viewing or coordinate logistics from 浙江温州 to your operation worldwide.

Caterpillar 349E

With a rated power of 309.5 kW and a working weight of 57,000 kg, the XCMG XE600DK is a robust choice for your heavy-duty excavation needs. Located in 浙江温州, this 2022 model is available now, ready to be deployed to your site without the delay of factory lead times. Equipped with a backhoe bucket and traditional power, it ensures efficient and reliable performance. Made in China, this machine is designed for logistics and speed, making it an ideal addition to any construction fleet. <ul><li>Available now in 浙江温州</li><li>Skip the factory lead times</li><li>Fast deployment to your site</li></ul>

XCMG XE600DK

With a working weight of 12,800 kg and a bucket capacity of 0.52 m³, the 2020 Kobelco SK130 is an ideal addition to any busy contractor's fleet. Powered by a reliable Mitsubishi D04FR engine, this excavator delivers 74 kW at 2000 rpm, ensuring robust performance on any job site. Its 90.1 kN bucket digging force and 70% climbing ability make it versatile for various terrains and tasks. Equipped with a 275-liter fuel tank, it offers extended operational hours, reducing downtime and increasing productivity. The compact design, with a total transport width of 2490 mm and height of 2710 mm, facilitates easy transportation between sites. Whether as a backup or a primary unit, the Kobelco SK130 enhances your fleet's efficiency and reliability.
<ul>
 <li>Working weight: 12,800 kg</li>
 <li>Bucket capacity: 0.52 m³</li>
 <li>Engine: Mitsubishi D04FR, 74 kW at 2000 rpm</li>
 <li>Bucket digging force: 90.1 kN</li>
 <li>Fuel tank: 275 L</li>
 <li>Total transport dimensions: 7790 x 2490 x 2710 mm (LxWxH)</li>
</ul>

Kobelco SK130

With a working weight of 61,000 kg and a bucket capacity ranging from 3.5 to 4.0 m³, the Sany SY650H is designed for heavy-duty performance. Made in China and powered by an Isuzu 6WG1 engine, this 65-ton excavator delivers a robust 345 kW of power. Equipped with a backhoe bucket, it excels in demanding environments, ensuring reliability and efficiency. Built to last, the SY650H has established itself as a proven workhorse, making it a reliable choice for construction and excavation projects. Located in Zhejiang, this machine is ready to tackle your toughest jobs with durability and strength.

Sany SY650H

Secure proven performance without the premium price tag. This 2016 Komatsu PC228US excavator delivers 22-ton capacity and traditional power reliability at a fraction of new equipment costs. Built by a joint venture manufacturer with import-grade standards, this machine combines Japanese engineering precision with practical operational efficiency. Currently located in Huizhou, Guangdong, it represents an intelligent capital allocation for contractors seeking maximum return on investment.

<ul>
<li>22-ton operating weight for versatile mid-range applications</li>
<li>Traditional power system ensures straightforward maintenance and lower operating costs</li>
<li>Backhoe configuration optimized for excavation and trenching operations</li>
<li>Joint venture/import manufacturing quality with Komatsu's proven durability</li>
<li>2016 model year provides modern features with significant cost savings versus new units</li>
<li>Available for immediate inspection in Huizhou, Guangdong</li>
</ul>

Smart buyers recognize that depreciation hits hardest in the first years. Acquire proven capability at optimal value while maintaining productivity standards your projects demand.

Komatsu PC228US

Built for operators who demand precision and endurance, the 2019 Kobelco SK260LC-8 is a 26-ton hydraulic excavator engineered in Japan and now available from Jiangsu, China. Powered by a Hino J05E four-cylinder, water-cooled turbocharged engine producing 131 kW at 2,100 rpm, this machine delivers consistent performance across demanding jobsites. The spacious, low-vibration cab offers wide-angle visibility and intuitive pilot controls, reducing operator fatigue during extended shifts. Standard hydraulic crushing pipelines add versatility straight from the factory.

<ul>
 <li>Engine: Hino J05E | 131 kW / 2,100 rpm | 5.123L displacement | Turbocharged, intercooled, direct injection</li>
 <li>Operating Weight: 25,200 kg | Bucket Capacity: 1.3 m³</li>
 <li>Digging Force: Bucket 170 kN | Arm 119 kN</li>
 <li>Maximum Digging Depth: 7,000 mm | Maximum Digging Radius: 10,310 mm</li>
 <li>Travel Speed: 3.6 / 5.8 km/h | Gradeability: 70% (35°)</li>
 <li>Main Pump: Dual variable displacement axial piston pumps | Max flow: 2 × 246 L/min</li>
 <li>Track Width: 600 mm | Transport Dimensions: 10,120 × 3,190 × 3,200 mm</l

Kobelco SK260LC-8

Acquire proven excavation power without the premium price tag. This 2016 Komatsu PC360-7 delivers 36-ton performance with a robust Komatsu SAA6D114E engine producing 180kW at 1900rpm. Engineered in Jining, Shandong Province, this machine combines Japanese precision with practical Chinese manufacturing efficiency.

Maximize your ROI with professional-grade specifications: a 1.6m³ bucket capacity, 11,100mm maximum digging radius, and 7,380mm digging depth handle demanding excavation projects with confidence. The 227kN bucket digging force and 171kN rod force tackle tough materials efficiently, while the 535L/min hydraulic flow ensures responsive operation across all functions.

Key advantages over new equipment:
<ul>
<li>33,000kg working weight provides exceptional stability on varied terrain</li>
<li>Proven 6-cylinder water-cooled engine with 8.27L displacement offers reliable power</li>
<li>70% gradeability and 5.5km/h travel speed maintain productivity on challenging sites</li>
<li>Currently located in Zhejiang for convenient inspection and delivery</li>
<li>Fraction of new equipment cost with comparable performance metrics</li>
</ul>

Smart operators recognize value when dependable machinery meets intelligent

Komatsu PC360-7

Engineered for maximum productivity, this 2016 XCMG XE700C delivers 70-ton performance through precision-built hydraulics and proven power systems. Equipped with a CUMMINS QSX15 turbocharged engine producing 336kW at 1800rpm, this excavator combines robust digging force with efficient fuel management across demanding job sites.

Dual plunger pumps supply 2×450 L/min flow capacity, generating 370kN bucket digging force and 330kN arm digging force—specifications that translate to faster cycle times and superior material handling in mining and heavy construction applications. The water-cooled 6-cylinder engine with 15L displacement maintains consistent performance under sustained loads, while the 3.1-3.5m³ bucket capacity optimizes payload efficiency.

Key technical specifications include:
<ul>
<li>Maximum digging reach: 11,580mm with 6,900mm depth capability</li>
<li>Operating weight: 68,000kg with 99.1kPa ground pressure distribution</li>
<li>Main system pressure: 34.3MPa for responsive control</li>
<li>Travel speed: 4.2km/h for rapid repositioning</li>
<li>980L fuel capacity supporting extended operation cycles</li>
</ul>

Currently located in Zhejiang, this Xuzhou-manufactured machine represents XCMG's commitme

XCMG XE700C

With a working weight of 33,000 kg and a bucket capacity of 1.6 m³, this 2014 Komatsu PC360-7 excavator offers robust performance for demanding projects. Located in Wenzhou, Zhejiang, this machine is powered by a reliable Komatsu SAA6D114E engine, delivering 180 kW at 1900 rpm. Featuring a 6-cylinder, water-cooled, direct injection, turbocharged engine, it ensures efficient and powerful operation.
<ul>
<li>Boasting a maximum digging depth of 7380 mm and a maximum excavation height of 10210 mm, it handles tough jobs with ease.</li>
<li>Equipped with axial plunger type hydraulic motors, it provides smooth and precise control, enhancing productivity on the job site.</li>
<li>Komatsu's reputation for durability and parts availability makes this model a safe investment, ensuring high resale value and minimal downtime.</li>
<li>Its strong market presence and widespread dealer network support quick and easy access to maintenance and replacement parts.</li>
</ul>

Specifications	Value
No.	1035572
Tonnage (tons)	48
Working weight (kg)	48400
Bucket capacity (m³)	2.2
Boom length (mm)	6550
Rod length (mm)	2900
power	Traditional power
manufacturer	Joint venture/Import
bucket	backhoe
Engine type	Cummins QSM11
Rated power (kw/rpm)	266/1900
Cooling mode	water-cooling
Cylinder diameter × stroke (mm)	125 x 147.1
Number of cylinders (PCS)	6
Displacement (L)	10.8
Rotation speed (rpm)	8.3
Climbing ability (%)	70
Travel speed (km/h)	4.7/2.9
Rotary hydraulic motor type	Axial plunger motor with automatic control
Maximum flow of main pump (l/min)	2*370
Main pump type	Two variable plunger pump
Bucket cylinders - Number × diameter × stroke (mm)	1 - ø 160 x ø 110 x 1370
Bucket rod cylinders - Number × diameter × stroke (mm)	1 - ø 190 x ø 130 x 1820
Boom cylinders - Number × diameter × stroke (mm)	2 - ø 170 x ø 115 x 1570
Pilot pump type	Gear pump
Fuel Tank (L)	620
Hydraulic Tank (L)	260
Engine Oil changes (L)	38
Coolant (L)	50
Hydraulic System (L)	380
Total transport length (mm)	11650
Total transport width (mm)	3340
Total transport height (mm)	3870
Full cab height (mm)	3190
Counterweight ground clearance (mm)	1295
Minimum turning radius of front working device (mm)	4500
Back end turning radius (mm)	3750
Onboard width (mm)	2980
Track plate width (mm)	600
Number of sprockets (single side) (each)	2
Number of wheels (single side) (each)	9
Number of track plates (single side) (PCS)	53
Maximum digging radius (mm)	11040
Maximum digging depth (mm)	6860
Maximum excavation height (mm)	10440
Maximum unloading height (mm)	7000
Maximum vertical digging depth (mm)	5830
Maximum excavation radius of stop surface (mm)	10820

2019 Hyundai R485LVS
