Product Description
Built for demanding excavation work, this 2021 Hyundai R495LVS delivers 49 tons of operational power to your jobsite in Luzhou, Sichuan. Equipped with a Cummins QSM11 engine producing 263 kW at 1900 rpm, this machine tackles deep foundation work, mass excavation, and heavy-duty grading with consistent performance. Maximum digging depth reaches 6,907 mm while the 11,057 mm digging radius provides extensive reach for large-scale earthmoving operations.
- Dual variable plunger pumps supply 2×380 L/min for responsive hydraulic control
- 45,875 kg working weight ensures stability during heavy lifting and digging cycles
- 70% climbing ability handles challenging terrain and steep site conditions
- 620L fuel capacity supports extended operation between refueling stops
- Water-cooled 6-cylinder engine with 10.8L displacement maintains power under load
Transport dimensions of 11,710 mm length accommodate standard lowboy trailers for efficient mobilization. With a 3,780 mm rear turning radius and proven Cummins power, this joint venture excavator arrives ready for demolition, trenching, and high-volume earthwork. Immediate deployment capability for contractors requiring reliable
| Specifications | Value |
|---|---|
| No. | 996820 |
| Tonnage (tons) | 49 |
| Working weight (kg) | 45875 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Cummins QSM11 |
| Rated power (kw/rpm) | 263/1900 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 125*147.1 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 10.8 |
| Rotation speed (rpm) | 8.5 |
| Climbing ability (%) | 70 |
| Travel speed (km/h) | 5.0/ 3.1 |
| Maximum flow of main pump (l/min) | 2*380 |
| Main pump type | Two variable plunger pump |
| Fuel Tank (L) | 620 |
| Hydraulic Tank (L) | 262 |
| Engine Oil changes (L) | 38 |
| Coolant (L) | 50 |
| Hydraulic System (L) | 486 |
| Total transport length (mm) | 11710 |
| Total transport width (mm) | 3340 |
| Total transport height (mm) | 3810 |
| Counterweight ground clearance (mm) | 1275 |
| Minimum turning radius of front working device (mm) | 4526 |
| Back end turning radius (mm) | 3780 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 53 |
| Maximum digging radius (mm) | 11057 |
| Maximum digging depth (mm) | 6907 |
| Maximum excavation height (mm) | 10363 |
| Maximum unloading height (mm) | 6983 |
| Maximum vertical digging depth (mm) | 5419 |
| Maximum excavation radius of stop surface (mm) | 10839 |
| Maximum effective digging depth (mm) | 6744 |
