Product Description
Engineered for precision and operator confidence, this 8-ton excavator delivers exceptional control across demanding jobsites. Powered by a reliable Yanmar 4TNV94L engine producing 44.7 kW, the machine combines responsive hydraulics with a dual variable axial piston pump system (2×75.6 l/min) for smooth, predictable operation. The spacious cab provides commanding visibility across a 6,330mm maximum digging radius, while intuitive pilot controls reduce fatigue during extended shifts.
Stability remains uncompromised with a 1,750mm track gauge and 32.3 kPa ground pressure distribution. Operators benefit from:
- Robust 44.1 kN bucket digging force for tough material penetration
- Compact 1,750mm rear swing radius enabling work in confined spaces
- 4,150mm maximum digging depth with 3,700mm boom reach
- Water-cooled 4-cylinder engine ensuring consistent performance
Located in Guangxi, this joint-venture manufactured unit represents proven Hyundai engineering with straightforward maintenance access and durable construction suited for high-utilization environments.
| Specifications | Value |
|---|---|
| No. | 1029578 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7801.8 |
| Bucket capacity (m³) | 0.28 |
| Boom length (mm) | 3700 |
| Rod length (mm) | 1670 |
| Country of origin | Peking |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar Yanma 4TNV94L |
| Rated power (kw/rpm) | 44.7 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.3 |
| Ground specific pressure (Kpa) | 32.3 |
| Rotation speed (rpm) | 12 |
| Bucket digging force (kN) | 44.1 |
| Rod digging force (kN) | 38.2 |
| Travel speed (km/h) | 4.8 |
| Rotary hydraulic motor type | Axial quantitative plunger motor |
| Type of walking hydraulic motor | Axial variable piston motor |
| Maximum flow of main pump (l/min) | 2 x 75.6 |
| Traveling Hydraulic Circuit (Mpa) | 30 |
| Rotary Hydraulic Circuit (Mpa) | 190 |
| Control Hydraulic Circuit (Mpa) | 3.5 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | 2× variable axial piston pump |
| Working Hydraulic Circuit (Mpa) | 28 |
| Pilot Oil Circuit (MPa) | 3.5 |
| Fuel Tank (L) | 135 |
| Engine Oil changes (L) | 12 |
| Coolant (L) | 10.8 |
| Hydraulic System (L) | 130 |
| Total transport length (mm) | 6325 |
| Total transport width (mm) | 2200 |
| Total transport height (mm) | 2640 |
| Full cab height (mm) | 2640 |
| Counterweight ground clearance (mm) | 760 |
| Minimum ground clearance (mm) | 360 |
| Back end turning radius (mm) | 1750 |
| Track gauge (mm) | 1750 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2200 |
| Track ground length (mm) | 2130 |
| Maximum digging radius (mm) | 6330 |
| Maximum digging depth (mm) | 4150 |
| Maximum excavation height (mm) | 7260 |
| Maximum unloading height (mm) | 5170 |
| Maximum vertical digging depth (mm) | 3200 |
| Maximum excavation radius of stop surface (mm) | 6190 |
