Product Description
Proven performance meets long-term value in this 2020 JohnDeere E130 excavator, currently located in Luzhou, Sichuan. Operating at 13 tons with a robust 80kW rated power output, this machine delivers consistent productivity across demanding jobsites. The 4.5L four-cylinder engine generates 445 N.m of maximum torque, while dual main pumps provide 126 L/min flow capacity for responsive hydraulic performance.
JohnDeere's reputation for reliability translates directly into lower ownership costs. Parts availability throughout China ensures minimal downtime, while the brand's strong resale value protects your investment. This E130 features a maximum digging reach of 8,351mm and digging depth of 5,764mm, backed by 101kN bucket digging force. With a 240L fuel tank and efficient hydraulic system, operational costs remain predictable and manageable.
- 13-ton working weight with 500mm track plates for stability
- 8,568mm maximum excavation height for versatile applications
- 70% climbing ability handles challenging terrain
- Joint venture/import quality with established dealer network
- Comprehensive specifications ensure transparent purchasing decisions
| Specifications | Value |
|---|---|
| No. | 994466 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13480 |
| Bucket capacity (m³) | |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2520 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | |
| Rated power (kw/rpm) | 80 / 1800 |
| Maximum torque (N.m) | 445 / 1400 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.5 |
| Working form | |
| Ground specific pressure (Kpa) | 43.6 |
| Rotation speed (rpm) | 12.5 |
| Climbing ability (%) | 70 (35°) |
| Bucket digging force (kN) | 101 |
| Rod digging force (kN) | 70 |
| Maximum tractive force (kN) | 139 |
| Travel speed (km/h) | 5.8 / 3.1 |
| Turning torque (Nm) | 35.8 |
| Maximum flow of main pump (l/min) | 126 x 2 |
| Traveling Hydraulic Circuit (Mpa) | 35.3 |
| Rotary Hydraulic Circuit (Mpa) | 27 |
| Main pump type | |
| Pilot Oil Circuit (MPa) | 3.9 |
| Pilot pump flow (L/min) | 18 x 1 |
| Fuel Tank (L) | 240 |
| Hydraulic Tank (L) | 125 |
| Engine Oil changes (L) | 14.7 |
| Coolant (L) | 18.2 |
| Hydraulic System (L) | 185 |
| Total transport length (mm) | 7632 |
| Total transport width (mm) | 2500 |
| Total transport height (mm) | 2841 |
| Full cab height (mm) | 2841 |
| Counterweight ground clearance (mm) | 888 |
| Minimum ground clearance (mm) | 434 |
| Minimum turning radius of front working device (mm) | 2626 |
| Back end turning radius (mm) | 2236 |
| Onboard width (mm) | 2500 |
| Total track length (mm) | 3501 |
| Track gauge (mm) | 2000 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2780 |
| Number of sprockets (single side) (each) | 1 |
| Number of wheels (single side) (each) | 6 |
| Number of track plates (single side) (PCS) | 43 |
| Maximum digging radius (mm) | 8351 |
| Maximum digging depth (mm) | 5764 |
| Maximum excavation height (mm) | 8568 |
| Maximum unloading height (mm) | 6030 |
| Maximum vertical digging depth (mm) | 5107 |
| Maximum excavation radius of stop surface (mm) | 8214 |
