Product Description
Strengthen your fleet capacity with this 2018 John Deere E210 excavator, currently located in Guizhou. Operating at 21 tons with a robust 117kW rated power output, this machine delivers consistent performance across demanding jobsites. Its 1.0m³ bucket capacity and impressive 10,040mm maximum digging radius make it an ideal secondary unit for contractors managing multiple projects simultaneously.
Built for reliability, this excavator features a 4.5L displacement engine producing 639N·m maximum torque, ensuring steady productivity during extended operations. The dual main pump system (224L/min × 2) provides responsive hydraulic performance, while the 5,680mm boom and 2,900mm arm configuration offer versatile reach for excavation, loading, and material handling tasks.
- Working weight: 21,100-23,100kg with proven stability
- Bucket digging force: 150kN for tough ground conditions
- Maximum digging depth: 6,730mm
- Travel speeds: 3.2/5.5 km/h for efficient repositioning
- 390L fuel capacity reduces refueling downtime
Add operational flexibility to your equipment roster with a machine engineered for consistent daily performance and fleet integration.
| Specifications | Value |
|---|---|
| No. | 1005362 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21100~23100 |
| Bucket capacity (m³) | 1.0 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | |
| Rated power (kw/rpm) | 117/2000 |
| Maximum torque (N.m) | 639/1500 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.5 |
| Working form | |
| Ground specific pressure (Kpa) | 38-58.3 |
| Rotation speed (rpm) | 12.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 150 |
| Rod digging force (kN) | 111 |
| Maximum tractive force (kN) | 216 |
| Travel speed (km/h) | 3.2/5.5 |
| Turning torque (Nm) | 61 |
| Maximum flow of main pump (l/min) | 224 x 2 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 27.3 |
| Main pump type | |
| Working Hydraulic Circuit (Mpa) | 34.3 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Pilot pump flow (L/min) | 20*1 |
| Fuel Tank (L) | 390 |
| Hydraulic Tank (L) | 141 |
| Engine Oil changes (L) | 14.7 |
| Coolant (L) | 26 |
| Hydraulic System (L) | 260 |
| Total transport length (mm) | 9790 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3299 |
| Full cab height (mm) | 3024 |
| Counterweight ground clearance (mm) | 1089 |
| Minimum ground clearance (mm) | 469 |
| Minimum turning radius of front working device (mm) | 3660 |
| Back end turning radius (mm) | 3042 |
| Total track length (mm) | 4072 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 45 |
| Maximum digging radius (mm) | 10040 |
| Maximum digging depth (mm) | 6730 |
| Maximum excavation height (mm) | 9810 |
| Maximum unloading height (mm) | 6790 |
| Maximum vertical digging depth (mm) | 6090 |
| Maximum excavation radius of stop surface (mm) | 9820 |
