Product Description
Engineered with precision hydraulics and robust power delivery, this 2018 John Deere E210 excavator sets a benchmark in the 21-ton class. At its core, a 4.5L four-cylinder engine generates 117 kW at 2,000 rpm with peak torque of 639 N·m, paired with dual main pumps flowing 224 liters per minute each. Working hydraulic circuits operate at 34.3 MPa, ensuring consistent performance across demanding jobsites.
- Power & Efficiency: 117 kW rated output with 4.5L displacement delivering optimal fuel-to-performance ratio
- Digging Performance: 150 kN bucket force and 10,040 mm maximum reach handle demanding excavation tasks
- Hydraulic Capacity: Dual 224 L/min pumps with 260L system capacity for smooth, responsive control
- Operational Range: 6,730 mm digging depth, 9,810 mm maximum height for versatile application
- Stability: 21,100–23,100 kg working weight with optimized ground pressure (38–58.3 kPa)
Currently located in Luzhou, Sichuan, this joint-venture model combines John Deere's engineering heritage with proven reliability for construction and mining operations worldwide.
| Specifications | Value |
|---|---|
| No. | 1023591 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21100~23100 |
| Bucket capacity (m³) | 1.0 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | |
| Rated power (kw/rpm) | 117/2000 |
| Maximum torque (N.m) | 639/1500 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.5 |
| Working form | |
| Ground specific pressure (Kpa) | 38-58.3 |
| Rotation speed (rpm) | 12.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 150 |
| Rod digging force (kN) | 111 |
| Maximum tractive force (kN) | 216 |
| Travel speed (km/h) | 3.2/5.5 |
| Turning torque (Nm) | 61 |
| Maximum flow of main pump (l/min) | 224 x 2 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 27.3 |
| Main pump type | |
| Working Hydraulic Circuit (Mpa) | 34.3 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Pilot pump flow (L/min) | 20*1 |
| Fuel Tank (L) | 390 |
| Hydraulic Tank (L) | 141 |
| Engine Oil changes (L) | 14.7 |
| Coolant (L) | 26 |
| Hydraulic System (L) | 260 |
| Total transport length (mm) | 9790 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3299 |
| Full cab height (mm) | 3024 |
| Counterweight ground clearance (mm) | 1089 |
| Minimum ground clearance (mm) | 469 |
| Minimum turning radius of front working device (mm) | 3660 |
| Back end turning radius (mm) | 3042 |
| Total track length (mm) | 4072 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 45 |
| Maximum digging radius (mm) | 10040 |
| Maximum digging depth (mm) | 6730 |
| Maximum excavation height (mm) | 9810 |
| Maximum unloading height (mm) | 6790 |
| Maximum vertical digging depth (mm) | 6090 |
| Maximum excavation radius of stop surface (mm) | 9820 |
