Product Description
Engineered with precision by Kato's joint-venture manufacturing in Japan, this 2016 HD1430V delivers 31-ton performance through proven Mitsubishi 6M60-TLE3A diesel power. Rated at 183 kW (2150 rpm) with 7.54L displacement and water-cooled efficiency, the six-cylinder engine drives dual variable-capacity piston pumps generating 307 l/min each at 31.4 MPa working pressure—ensuring responsive hydraulic flow across all functions.
Technical capabilities include:
- Maximum digging reach of 11,180 mm with 7,450 mm depth capacity
- Bucket breakout force: 224 kN (Standard) / 235 kN (Extra mode)
- Boom length 6,480 mm paired with 3,140 mm arm for optimal geometry
- Bucket capacity range: 1.1–1.8 m³ for application versatility
- 70% gradeability with 62 kPa ground pressure minimizing site impact
- Dual-speed travel: 3.9 / 5.7 km/h for maneuverability
Currently positioned in Dongguan, Guangdong, this excavator combines Japanese engineering standards with field-proven hydraulic architecture. Complete with 650L fuel capacity and robust undercarriage (600 mm shoes, 3,760 mm track contact), the HD1430V represents reliable heavy-duty excavation capability for demanding operations.<
| Specifications | Value |
|---|---|
| No. | 1046189 |
| Tonnage (tons) | 31 |
| Working weight (kg) | 31000 |
| Bucket capacity (m³) | 1.1-1.8 |
| Boom length (mm) | 6480 |
| Rod length (mm) | 3140 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi 6M60-TLE3A |
| Rated power (kw/rpm) | 183/2150 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 118 x 115 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.54 |
| Ground specific pressure (Kpa) | 62 |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 224 (Standard mode) /235 (Extra mode) |
| Rod digging force (kN) | 159 (Standard Mode) /166 (Power mode) |
| Travel speed (km/h) | 3.9/5.7 |
| Rotary hydraulic motor type | Constant piston motor |
| Type of walking hydraulic motor | Variable capacity piston motor |
| Maximum flow of main pump (l/min) | 307 x 2 |
| Traveling Hydraulic Circuit (Mpa) | 32.9 |
| Main pump type | Variable capacity piston pump ×2+ gear pump |
| Working Hydraulic Circuit (Mpa) | 31.4 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-150 x 1230 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-170 x 1840 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-150 x 1450 |
| Fuel Tank (L) | 650 |
| Hydraulic Tank (L) | 200 |
| Engine Oil changes (L) | 32 |
| Coolant (L) | 44 |
| Hydraulic System (L) | 404 |
| Total transport length (mm) | 11200 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3370 |
| Full cab height (mm) | 3020 |
| Counterweight ground clearance (mm) | 1130 |
| Minimum ground clearance (mm) | 500 |
| Minimum turning radius of front working device (mm) | 4640 |
| Back end turning radius (mm) | 3460 |
| Total track length (mm) | 4650 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 3760 |
| Maximum digging radius (mm) | 11180 |
| Maximum digging depth (mm) | 7450 |
| Maximum excavation height (mm) | 10330 |
| Maximum unloading height (mm) | 7280 |
| Maximum vertical digging depth (mm) | 5950 |
