Product Description
Expand your operational capacity with this 2016 Kato HD512V excavator, a proven 12-ton performer built to slot seamlessly into multi-machine fleets. Powered by a reliable 71kW engine and equipped with a 0.5m³ backhoe bucket, this joint-venture manufactured unit delivers consistent productivity across medium-duty excavation tasks. With 5,600mm maximum digging depth and 8,310mm reach, it handles trenching, grading, and site preparation without straining your primary equipment rotation.
- Operating Weight: 13,200kg – balanced footprint for transport and stability
- Digging Performance: 8,750mm max excavation height, 6,390mm unloading clearance
- Transport Dimensions: 8,000 × 2,490 × 2,460mm – standard trailer-friendly profile
- Track Configuration: 500mm-wide plates, 2,870mm ground contact for secure footing
- Ground Clearance: 880mm counterweight, 440mm minimum – suitable for varied terrain
Currently located in Chaozhou, Guangdong, this HD512V offers fleet managers a cost-effective backup solution that minimizes downtime during peak workloads or scheduled maintenance cycles. Traditional power trai
| Specifications | Value |
|---|---|
| No. | 1051193 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 13200 |
| Bucket capacity (m³) | 0.5 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Rated power (kw/rpm) | 71 / 2000 |
| Total transport length (mm) | 8000 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2460 |
| Counterweight ground clearance (mm) | 880 |
| Minimum ground clearance (mm) | 440 |
| Total track length (mm) | 3570 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2870 |
| Maximum digging radius (mm) | 8310 |
| Maximum digging depth (mm) | 5600 |
| Maximum excavation height (mm) | 8750 |
| Maximum unloading height (mm) | 6390 |
| Maximum vertical digging depth (mm) | 4610 |
