Product Description
Built for immediate deployment on demanding job sites, this 2016 Kato HD513MR-6 delivers proven performance across excavation, grading, and material handling operations. Operating at 13 tons with a 75kW rated power output, this joint venture-manufactured excavator combines precision control with robust digging capabilities. The 0.25-0.60 m³ bucket capacity adapts to varied site requirements, while the 8460mm maximum digging radius and 5560mm maximum digging depth provide extensive working range for foundation work, trenching, and site preparation tasks.
- 13,700 kg working weight optimized for stability and maneuverability
- Traditional power system with 75kW at 2000 rpm for consistent performance
- Compact transport dimensions: 7540mm length × 2490mm width × 2800mm height
- 500mm track plates with 2870mm ground contact length ensure solid traction
- Maximum unloading height of 6680mm for efficient truck loading
- 440mm minimum ground clearance for navigating uneven terrain
- Currently located in Guangxi, ready for site mobilization
Purpose-engineered for contractors requiring reliable backhoe performance, this machine stands ready to tackle your next
| Specifications | Value |
|---|---|
| No. | 1010302 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13700 |
| Bucket capacity (m³) | 0.25 - 0.60 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Rated power (kw/rpm) | 75 / 2000 |
| Total transport length (mm) | 7540 (7550) |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2800 |
| Full cab height (mm) | 2760 |
| Counterweight ground clearance (mm) | 880 |
| Minimum ground clearance (mm) | 440 (430) |
| Total track length (mm) | 3570 (3740) |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2490 |
| Track ground length (mm) | 2870 (3040) |
| Maximum digging radius (mm) | 8460 (8930) |
| Maximum digging depth (mm) | 5560 (6060) |
| Maximum excavation height (mm) | 9060 (9410) |
| Maximum unloading height (mm) | 6680 (7030) |
| Maximum vertical digging depth (mm) | 4560 (5300) |
