Product Description
This 2020 Kobelco SK210LC-9 excavator is available from Shandong, China, offering reliable performance for demanding applications. The machine features a 16-meter long reach boom that was installed just one month ago, providing extended working range for specialized tasks. Currently located in Shandong province, this unit is well-suited for deep excavation, demolition, and material handling operations.
- Year: 2020
- Model: Kobelco SK210LC-9
- 16-meter long reach boom (recently installed)
- Standard boom included with sale
- Well-maintained undercarriage
- Responsive hydraulic system
- Single-operator ownership
- Location: Shandong, China
The seller reports consistent maintenance history and reliable operation throughout its service life. Both the extended boom configuration and standard arm are included in the sale, offering operational flexibility for various job site requirements.
| Specifications | Value |
|---|---|
| No. | 1138349 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21600/21800/22000 |
| Bucket capacity (m³) | 0.7/0.8/0.93 |
| Boom length (mm) | 5650 |
| Rod length (mm) | 2940 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | HINO Hino J05E-TA |
| Rated power (kw/rpm) | 124/2000 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 6.7 |
| Working form | Direct injection; Turbocharged, intercooled, meets EPA Tier IV and EU Stage IIIB |
| Ground specific pressure (Kpa) | 33.8 |
| Rotation speed (rpm) | 12.5 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 229 |
| Rod digging force (kN) | 222 |
| Maximum tractive force (kN) | 229 |
| Travel speed (km/h) | 6.0/3.6 |
| Type of walking hydraulic motor | Axial piston pump x 2 |
| Maximum flow of main pump (l/min) | 2 x 220 |
| Main pump type | Double variable pump + single gear pump |
| Pilot pump flow (L/min) | 20 |
| Fuel Tank (L) | 370 |
| Hydraulic Tank (L) | 130 |
| Engine Oil changes (L) | 20 |
| Coolant (L) | 26 |
| Hydraulic System (L) | 230 |
| Total transport length (mm) | 9560 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 2980 |
| Full cab height (mm) | 3080 |
| Counterweight ground clearance (mm) | 1060 |
| Minimum ground clearance (mm) | 450 |
| Minimum turning radius of front working device (mm) | 3540 |
| Back end turning radius (mm) | 6910 |
| Onboard width (mm) | 2710 |
| Track gauge (mm) | 2390 |
| Track plate width (mm) | 800 |
| Track ground length (mm) | 3660 |
| Maximum digging radius (mm) | 9900 |
| Maximum digging depth (mm) | 6700 |
| Maximum excavation height (mm) | 9720 |
| Maximum vertical digging depth (mm) | 6100 |
| Maximum excavation radius of stop surface (mm) | 9730 |
| Maximum effective digging depth (mm) | 6520 |
