Product Description
Discover the 2023 Kobelco ED150, a robust and reliable excavator currently available in Zhejiang, China. This machine is ideal for a wide range of construction and excavation projects, offering the durability and performance that Kobelco is known for. With its efficient engine and advanced hydraulic system, the ED150 ensures optimal productivity and fuel efficiency on any job site.
- Year: 2023
- Brand: Kobelco
- Model: ED150
- Location: Zhejiang, China
| Specifications | Value |
|---|---|
| No. | 1078191 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 16202.3 |
| Bucket capacity (m³) | 0.38/0.23/0.67 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu A-4BG1T |
| Rated power (kw/rpm) | 70.1/2200 |
| Displacement (L) | 4.3 |
| Ground specific pressure (Kpa) | 42.7 |
| Bucket digging force (kN) | 145 |
| Travel speed (km/h) | 5 |
| Fuel Tank (L) | 168 |
| Engine Oil changes (L) | 13 |
| Coolant (L) | 18 |
| Hydraulic System (L) | 140 |
| Total transport length (mm) | 8550 |
| Total transport width (mm) | 2590 |
| Total transport height (mm) | 2980 |
| Full cab height (mm) | 2900 |
| Counterweight ground clearance (mm) | 1070 |
| Minimum ground clearance (mm) | 525 |
| Back end turning radius (mm) | 1430 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 2800 |
| Maximum digging depth (mm) | 5850 |
| Maximum excavation height (mm) | 9020 |
| Maximum unloading height (mm) | 6600 |
| Maximum vertical digging depth (mm) | 5090 |
| Maximum excavation radius of stop surface (mm) | 8620 |
