Product Description
Equipped with a Mitsubishi D04FR engine, delivering 74 kW at 2000 rpm, the 2015 Kobelco SK130 offers robust performance and reliability. Featuring a hydraulic system that ensures precise control and efficiency, this excavator is designed for demanding tasks. With a bucket capacity of 0.52 m³ and a digging force of 90.1 kN, it handles tough materials effortlessly. The machine's climbing ability of 70% and 35° gradeability make it versatile in various terrains. Built with a total transport length of 7790 mm and a width of 2490 mm, the SK130 is both maneuverable and powerful. Its full cab height of 2870 mm and minimum ground clearance of 440 mm ensure operator comfort and safety. This Japanese-engineered model, manufactured through a joint venture, combines traditional power with advanced engineering, making it a top choice for construction and excavation projects.
| Specifications | Value |
|---|---|
| No. | 1030781 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12800 |
| Bucket capacity (m³) | 0.52 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi D04FR |
| Rated power (kw/rpm) | 74/2000 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 90.1 |
| Travel speed (km/h) | 3.4/5.6 |
| Fuel Tank (L) | 275 |
| Hydraulic Tank (L) | 101 |
| Total transport length (mm) | 7790 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2710 |
| Full cab height (mm) | 2870 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2190 |
| Onboard width (mm) | 2490 |
| Total track length (mm) | 3580 |
| Track gauge (mm) | 2870 |
| Track plate width (mm) | 500/600/700 |
| Maximum digging radius (mm) | 8340 |
| Maximum digging depth (mm) | 5520 |
| Maximum excavation height (mm) | 8500 |
| Maximum unloading height (mm) | 6090 |
| Maximum vertical digging depth (mm) | 4880 |
| Dodging plate width × height (mm) | 500 |
| Maximum excavation radius of stop surface (mm) | 8190 |
| Maximum effective digging depth (mm) | 5290 |
