Product Description
Built for demanding excavation work, this 2017 Kobelco SK130 delivers 13-ton performance with Japanese engineering precision. Powered by a Mitsubishi D04FR engine producing 74kW at 2000 rpm, this mid-size excavator handles trenching, grading, and site preparation with proven reliability. Currently located in Guizhou, the machine is ready for immediate deployment on construction, demolition, or earthmoving projects.
- Maximum Digging Depth: 5,520mm – reach deep for foundations and utility trenching
- Bucket Digging Force: 90.1kN – power through compacted soil and challenging materials
- 0.52m³ Backhoe Bucket: optimal capacity for loading trucks and mass excavation
- 8,340mm Working Radius: extended reach reduces repositioning time
- 2,190mm Tail Swing Radius: maneuver efficiently in confined spaces
- 70% Climbing Ability: tackle sloped terrain and uneven ground conditions
Working weight of 12,800kg provides stable operation during high-force digging cycles. Dual travel speeds (3.4/5.6 km/h) balance precision positioning with productive site mobility. Factory-sp
| Specifications | Value |
|---|---|
| No. | 1017602 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12800 |
| Bucket capacity (m³) | 0.52 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi D04FR |
| Rated power (kw/rpm) | 74/2000 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 90.1 |
| Travel speed (km/h) | 3.4/5.6 |
| Fuel Tank (L) | 275 |
| Hydraulic Tank (L) | 101 |
| Total transport length (mm) | 7790 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2710 |
| Full cab height (mm) | 2870 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2190 |
| Onboard width (mm) | 2490 |
| Total track length (mm) | 3580 |
| Track gauge (mm) | 2870 |
| Track plate width (mm) | 500/600/700 |
| Maximum digging radius (mm) | 8340 |
| Maximum digging depth (mm) | 5520 |
| Maximum excavation height (mm) | 8500 |
| Maximum unloading height (mm) | 6090 |
| Maximum vertical digging depth (mm) | 4880 |
| Dodging plate width × height (mm) | 500 |
| Maximum excavation radius of stop surface (mm) | 8190 |
| Maximum effective digging depth (mm) | 5290 |
