Product Description
Built for immediate deployment, this 2019 Kobelco SK130 excavator delivers proven performance across demanding jobsites. Operating at 13 tons with a 12,800 kg working weight, this machine combines Japanese engineering precision with practical power. The Mitsubishi D04FR engine generates 74 kW at 2000 rpm, providing consistent hydraulic force for continuous operation. Currently located in Shaoxing, Zhejiang, this unit arrives ready to tackle excavation, grading, and material handling tasks without delay.
- Maximum digging depth of 5,520 mm reaches deep trenching requirements
- 8,340 mm digging radius covers extensive work zones from single positions
- 90.1 kN bucket digging force breaks through compacted soil and challenging materials
- 0.52 m³ bucket capacity balances cycle times with payload efficiency
- 70% climbing ability (35°) maintains productivity on sloped terrain
- 275L fuel tank supports extended shifts with minimal refueling interruptions
- Compact 2,490 mm transport width enables navigation through restricted access points
Equipped with backhoe configuration and proven joint venture manufacturing standards, this SK130 stands ready for site
| Specifications | Value |
|---|---|
| No. | 1005238 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12800 |
| Bucket capacity (m³) | 0.52 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi D04FR |
| Rated power (kw/rpm) | 74/2000 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 90.1 |
| Travel speed (km/h) | 3.4/5.6 |
| Fuel Tank (L) | 275 |
| Hydraulic Tank (L) | 101 |
| Total transport length (mm) | 7790 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2710 |
| Full cab height (mm) | 2870 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2190 |
| Onboard width (mm) | 2490 |
| Total track length (mm) | 3580 |
| Track gauge (mm) | 2870 |
| Track plate width (mm) | 500/600/700 |
| Maximum digging radius (mm) | 8340 |
| Maximum digging depth (mm) | 5520 |
| Maximum excavation height (mm) | 8500 |
| Maximum unloading height (mm) | 6090 |
| Maximum vertical digging depth (mm) | 4880 |
| Dodging plate width × height (mm) | 500 |
| Maximum excavation radius of stop surface (mm) | 8190 |
| Maximum effective digging depth (mm) | 5290 |
