Product Description
Built for precision work in confined spaces, this 2020 Kobelco SK130 delivers 13-ton performance with exceptional operator control. Powered by a reliable Mitsubishi D04FR engine generating 74 kW at 2000 rpm, this midsize excavator combines robust digging力 (90.1 kN bucket force) with a compact 2190 mm rear swing radius—ideal for urban construction and infrastructure projects.
- Superior Visibility: Cab-mounted design at 2870 mm height provides commanding sightlines to bucket and work zone, reducing blind spots during material handling
- Responsive Hydraulics: 11.5 rpm rotation speed enables smooth, controlled positioning in tight quarters
- Stable Platform: 2870 mm track gauge and 12,800 kg working weight ensure minimal lateral sway during reach operations up to 8340 mm
- Operational Stamina: 275L fuel tank supports extended shifts without refueling interruptions
- Versatile Reach: Maximum digging depth of 5520 mm handles utility trenching and foundation work with consistent penetration force
Currently located in Hunan, China. Factory-spec Kobelco engineering with proven Japanese build quality fr
| Specifications | Value |
|---|---|
| No. | 1030796 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12800 |
| Bucket capacity (m³) | 0.52 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi D04FR |
| Rated power (kw/rpm) | 74/2000 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 90.1 |
| Travel speed (km/h) | 3.4/5.6 |
| Fuel Tank (L) | 275 |
| Hydraulic Tank (L) | 101 |
| Total transport length (mm) | 7790 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2710 |
| Full cab height (mm) | 2870 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2190 |
| Onboard width (mm) | 2490 |
| Total track length (mm) | 3580 |
| Track gauge (mm) | 2870 |
| Track plate width (mm) | 500/600/700 |
| Maximum digging radius (mm) | 8340 |
| Maximum digging depth (mm) | 5520 |
| Maximum excavation height (mm) | 8500 |
| Maximum unloading height (mm) | 6090 |
| Maximum vertical digging depth (mm) | 4880 |
| Dodging plate width × height (mm) | 500 |
| Maximum excavation radius of stop surface (mm) | 8190 |
| Maximum effective digging depth (mm) | 5290 |
