2020 Kobelco SK130

Built for operators who demand precision and control, the 2020 Kobelco SK130 delivers a refined excavating experience in a proven 13-ton platform. Powered by a Mitsubishi D04FR engine producing 74 kW at 2,000 RPM, this Japanese-engineered machine handles demanding dig cycles with consistent hydraulic response and a bucket digging force of 90.1 kN. Currently available from Fujian, China, it is ready for immediate export.

From the operator's seat, wide cab glass and low front hood lines provide clear sightlines to the work area — critical when managing precise placements at a maximum digging depth of 5,520 mm or unloading at heights up to 6,090 mm. The ergonomic layout reduces fatigue during long shifts, while the stable undercarriage — spanning a 2,870 mm track gauge with 500/600/700 mm plate width options — holds firm on grades up to 70% (35°).

• Engine: Mitsubishi D04FR — 74 kW / 2,000 RPM
• Operating Weight: 12,800 kg | Bucket Capacity: 0.52 m³
• Max Digging Radius: 8,340 mm | Max Digging Depth: 5,520 mm
• Travel Speed: 3.4 / 5.6 km/h | Climbing Ability: 70% / 35°
• Fuel Tank: 275 L | Hydraulic Tank: 101 L
• Transport Dimensions: 7,790 × 2,490 × 2,710 mm
