Product Description
Built for precision and daily productivity, this 2021 Kobelco SK200 excavator delivers reliable 20-ton performance with operator-focused engineering. Powered by a Mitsubishi 6D34-TLU2D engine producing 110kW at 2000rpm, it combines responsive hydraulics with stable ground contact across varied terrain. Operators benefit from excellent cabin visibility and intuitive controls that reduce fatigue during extended shifts.
- Operating Weight: 20,000 kg with 0.8 m³ bucket capacity
- Digging Power: 143 kN bucket force (157 kN supercharged); 97.1 kN arm force (107 kN supercharged)
- Stability: Low ground pressure (45/35 kPa) and 70% climbing ability
- Hydraulics: Double variable displacement axial piston pump with 34.3 MPa pressure (37.8 MPa supercharged)
- Travel Speed: Dual-speed capability—4.0 km/h (low), 6.0 km/h (high)
- Location: Shandong, China
Water-cooled turbocharged engine with intercooling ensures consistent performance. Track widths available in 600mm or 800mm configurations for site-specific requirements.
| Specifications | Value |
|---|---|
| No. | 1015094 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 20000 |
| Bucket capacity (m³) | 0.8 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi 6D34-TLU2D |
| Rated power (kw/rpm) | 110/2000 |
| Cooling mode | water-cooling |
| Working form | Water-cooled, four-stroke, six-cylinder, direct injection, turbocharged, built-in intercooling |
| Ground specific pressure (Kpa) | 45; 35 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 143; Supercharged state: 157 |
| Rod digging force (kN) | 97.1; Supercharged state: 107 |
| Travel speed (km/h) | 1 speed: 4.0 2 speed :6.0 |
| Main overflow set pressure (Mpa) | 34.3; Supercharged state: 37.8 |
| Main pump type | Double variable displacement axial piston pump pilot gear pump |
| Fuel Tank (L) | 340 |
| Track plate width (mm) | 600; 800 |
