Product Description
Engineered for precision and daily productivity, this 2021 Kobelco SK200 excavator delivers exceptional operator comfort and machine control across demanding jobsites. Powered by a Mitsubishi 6D34-TLU2D engine generating 110 kW at 2000 rpm, this 20-ton workhorse combines turbocharged performance with water-cooled reliability. Operators benefit from responsive hydraulics driven by dual variable displacement axial piston pumps, providing smooth bucket and arm movements throughout the working cycle.
- Superior Visibility: Spacious cabin design offers commanding 360-degree sightlines for enhanced safety and load placement accuracy
- Proven Stability: Ground pressure options of 45 kPa (600mm tracks) or 35 kPa (800mm tracks) ensure balanced performance on varied terrain
- Digging Power: Bucket force reaches 157 kN in supercharged mode with 0.8 m³ capacity for efficient material handling
- Extended Operation: 340-liter fuel tank supports full-shift runtime with minimal refueling interruptions
- Current Location: Jiangsu, China—ready for global export
Built to joint venture/import standards, this SK200
| Specifications | Value |
|---|---|
| No. | 1023859 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 20000 |
| Bucket capacity (m³) | 0.8 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi 6D34-TLU2D |
| Rated power (kw/rpm) | 110/2000 |
| Cooling mode | water-cooling |
| Working form | Water-cooled, four-stroke, six-cylinder, direct injection, turbocharged, built-in intercooling |
| Ground specific pressure (Kpa) | 45; 35 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 143; Supercharged state: 157 |
| Rod digging force (kN) | 97.1; Supercharged state: 107 |
| Travel speed (km/h) | 1 speed: 4.0 2 speed :6.0 |
| Main overflow set pressure (Mpa) | 34.3; Supercharged state: 37.8 |
| Main pump type | Double variable displacement axial piston pump pilot gear pump |
| Fuel Tank (L) | 340 |
| Track plate width (mm) | 600; 800 |
