Product Description
Built for productivity, this 2016 Kobelco SK200-9 excavator delivers reliable performance across excavation, grading, and demolition projects. Powered by a Hino J05E-TJ engine generating 117kW at 2000rpm, this 20-ton machine combines efficient fuel consumption with robust digging force—143kN bucket force and 102kN arm force handle demanding ground conditions without hesitation.
Currently located in Putian, Fujian, this SK200-9 arrives site-ready with proven specifications:
- Operating weight: 19,900kg with 0.80m³ bucket capacity
- Maximum digging reach: 9,900mm; digging depth: 6,700mm
- Travel speeds: 6.0km/h (high) / 3.6km/h (low) for efficient repositioning
- 370L fuel tank supports extended operational shifts
- 70% grading ability tackles challenging terrain
- Compact transport dimensions: 9,560mm × 2,800mm × 3,070mm
This joint-venture manufactured excavator provides the durability and precision required for earthmoving contractors, site developers, and demolition specialists. Ready to deploy immediately for your next project.
| Specifications | Value |
|---|---|
| No. | 1031350 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 19900 |
| Bucket capacity (m³) | 0.80 / 0.59 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Hino J05E-TJ |
| Rated power (kw/rpm) | 117 / 2000 |
| Ground specific pressure (Kpa) | 45 |
| Rotation speed (rpm) | 12.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 143 |
| Rod digging force (kN) | 102 |
| Travel speed (km/h) | 6.0/3.6 (High/Low) |
| Fuel Tank (L) | 370 |
| Total transport length (mm) | 9560 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3070 |
| Maximum digging radius (mm) | 9900 |
| Maximum digging depth (mm) | 6700 |
| Maximum excavation height (mm) | 9720 |
| Maximum vertical digging depth (mm) | 6100 |
