Product Description
Built for demanding excavation work, this 2020 Kobelco SK330-10 delivers proven performance with the backing of a globally recognized manufacturer. Operating at 33 tons with a robust Hino J08ETM-KSDL engine producing 209kW at 2100rpm, this machine combines power and precision for heavy-duty applications. The 1.5m³ bucket capacity and 7560mm maximum digging depth ensure productivity across diverse jobsites, while the water-cooled, turbocharged engine with intercooling maintains consistent performance under load.
Kobelco's reputation in the used equipment market stands on solid ground. Parts availability remains excellent through established dealer networks, minimizing downtime and maintenance costs. Strong resale values reflect the brand's durability and operator preference, protecting your investment long-term. Located in Zhejiang Shaoxing, this SK330-10 features the reliable joint venture/import build quality that contractors depend on.
- Maximum digging radius: 11260mm
- Bucket digging force: 229kN
- Fuel capacity: 503L for extended operation
- Travel speed: 5.6km/h (high) / 3.3km/h (low)
- Proven Hino engine technology with 998N.m maximum torque
| Specifications | Value |
|---|---|
| No. | 994349 |
| Tonnage (tons) | 33 |
| Working weight (kg) | 34500 |
| Bucket capacity (m³) | 1.5 |
| Rod length (mm) | 3300 |
| Bucket width (mm) | 1390 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Hino J08ETM-KSDL |
| Rated power (kw/rpm) | 209/2100 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 998/1600 |
| Working form | Direct injection, water-cooled, four-stroke, turbocharged, built-in intercooling |
| Ground specific pressure (Kpa) | 70 |
| Rotation speed (rpm) | 10.0 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 229 |
| Rod digging force (kN) | 165 |
| Maximum tractive force (kN) | 333 |
| Travel speed (km/h) | 5.6/3.3 |
| Main overflow set pressure (Mpa) | 34.3 |
| Rotary hydraulic motor type | Axial piston pump motor ×1 |
| Type of walking hydraulic motor | Variable capacity axial piston motor x 2 |
| Main pump type | Double variable displacement axial piston pump + pilot gear pump |
| Fuel Tank (L) | 503 |
| Hydraulic Tank (L) | 245 |
| Hydraulic System (L) | 410 |
| Total transport length (mm) | 11300 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3430 |
| Full cab height (mm) | 3150 |
| Counterweight ground clearance (mm) | 1190 |
| Minimum ground clearance (mm) | 500 |
| Onboard width (mm) | 2980 |
| Total track length (mm) | 4630 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3720 |
| Maximum digging radius (mm) | 11260 |
| Maximum digging depth (mm) | 7560 |
| Maximum excavation height (mm) | 10540 |
| Maximum unloading height (mm) | 7370 |
| Maximum vertical digging depth (mm) | 6480 |
| Maximum excavation radius of stop surface (mm) | 11060 |
