Product Description
Built for high-output excavation, this 2014 Kobelco SK350LC SuperX delivers 35-ton class performance with proven Hino diesel power. Currently located in Luzhou, Sichuan, this crawler excavator combines a 6500mm boom and 3300mm arm with a 1.6m³ backhoe bucket—configured for immediate deployment on digging, grading, and demolition projects.
- Power & Force: 209kW Hino J08ETM engine paired with 229kN bucket digging force and 165kN arm force handles dense material and deep trenching applications
- Reach & Depth: Maximum digging radius of 11260mm and depth capacity to 7560mm enable work across large excavation sites without repositioning
- Mobility: 70% gradeability and dual travel speeds (5.6/3.3 km/h) provide stable movement on uneven terrain
- Operating Efficiency: 503L fuel tank supports extended shifts; 10.0 rpm swing speed maintains productive cycle times
Weighing 35,300kg with 600mm track shoes and 66kPa ground pressure, this machine balances stability with site versatility. Ready for contractors requiring reliable excavation capacity.
| Specifications | Value |
|---|---|
| No. | 1018464 |
| Tonnage (tons) | 35 |
| Working weight (kg) | 35300 |
| Bucket capacity (m³) | 1.6 |
| Boom length (mm) | 6500 |
| Rod length (mm) | 3300 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Hino J08ETM-KSDL |
| Rated power (kw/rpm) | 209/2100 |
| Maximum torque (N.m) | 998/1600 |
| Ground specific pressure (Kpa) | 66 |
| Rotation speed (rpm) | 10.0 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 229 |
| Rod digging force (kN) | 165 |
| Maximum tractive force (kN) | 333 |
| Travel speed (km/h) | 5.6/3.3 |
| Fuel Tank (L) | 503 |
| Hydraulic Tank (L) | 245 |
| Hydraulic System (L) | 410 |
| Total transport length (mm) | 11300 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3430 |
| Minimum turning radius of front working device (mm) | 4310 |
| Track plate width (mm) | 600 |
| Maximum digging radius (mm) | 11260 |
| Maximum digging depth (mm) | 7560 |
| Maximum excavation height (mm) | 10540 |
| Maximum unloading height (mm) | 7370 |
| Maximum vertical digging depth (mm) | 6480 |
| Maximum excavation radius of stop surface (mm) | 11060 |
see more
Overview
No.1018464
Brand Name：
KobelcoModel Number：
SK350LC SuperXYear：
2014
Location：
Sichuan China
Pub Date：
