Product Description
Built for demanding excavation projects, this 2019 Kobelco SK380XD-10 delivers 38-ton performance with precision hydraulic control. Located in Zhejiang Shaoxing, this machine combines a powerful 197kW Hino engine with advanced double variable displacement pumping systems for consistent productivity across heavy-duty applications.
Key operational specifications include:
- Maximum digging depth of 6,840mm with 229kN bucket digging force
- 10,610mm maximum digging radius for extended reach capabilities
- 1.9m³ bucket capacity optimized for high-volume material handling
- 503L fuel tank supporting extended operational periods
- 70% climbing ability (35°) for challenging terrain navigation
Engineered with water-cooled direct injection technology and turbocharged intercooling, this excavator maintains consistent power output during intensive digging, grading, and demolition operations. Advanced axial piston hydraulic motors ensure precise control while the reinforced undercarriage provides stability on varied ground conditions. Ready for immediate deployment with proven reliability in construction and earthmoving applications.
| Specifications | Value |
|---|---|
| No. | 992519 |
| Tonnage (tons) | 38 |
| Working weight (kg) | 38500 |
| Bucket capacity (m³) | 1.9 |
| Boom length (mm) | 2600 |
| Rod length (mm) | 6500 |
| Bucket width (mm) | 1740 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Hino J08ETM-KSDL |
| Rated power (kw/rpm) | 197/2100 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 968/1600 |
| Working form | Direct injection, four stroke, turbocharged, built-in intercooling |
| Ground specific pressure (Kpa) | 72 |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 70 (35°) |
| Bucket digging force (kN) | 229 |
| Rod digging force (kN) | 207 |
| Maximum tractive force (kN) | 331 |
| Travel speed (km/h) | 5.6/3.3 |
| Main overflow set pressure (Mpa) | 34.3 |
| Rotary hydraulic motor type | Axial piston pump motor (1) |
| Type of walking hydraulic motor | Variable capacity axial piston motors (2) |
| Main pump type | Double variable displacement axial piston pump + pilot gear pump |
| Fuel Tank (L) | 503 |
| Hydraulic Tank (L) | 245 |
| Hydraulic System (L) | 410 |
| Total transport length (mm) | 11380 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3710 |
| Full cab height (mm) | 3230 |
| Counterweight ground clearance (mm) | 1210 |
| Minimum ground clearance (mm) | 515 |
| Minimum turning radius of front working device (mm) | 4460 |
| Total track length (mm) | 4980 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 4050 |
| Maximum digging radius (mm) | 10610 |
| Maximum digging depth (mm) | 6840 |
| Maximum excavation height (mm) | 10230 |
| Maximum unloading height (mm) | 7070 |
| Maximum vertical digging depth (mm) | 5700 |
| Maximum excavation radius of stop surface (mm) | 10400 |
Overview
No.992519
Brand Name：
KobelcoModel Number：
SK380XD-10Year：
2019
Location：
Zhejiang China
