Product Description
Built for the long haul, this 2016 Kobelco SK480 excavator stands as a proven workhorse in heavy-duty earthmoving operations. With eight years of reliable service behind it, this 48-ton machine demonstrates the exceptional build quality Kobelco is renowned for worldwide. Powered by traditional diesel technology and equipped with a substantial 2.3m³ backhoe bucket, it delivers consistent performance across demanding job sites.
- Impressive Reach: Maximum digging radius of 11,700mm and depth of 7,370mm
- Substantial Power: 48-ton operating weight with 7,000mm boom length
- Proven Reliability: Joint venture/Import manufacturing quality since 2016
- Versatile Performance: Maximum excavation height of 11,160mm for diverse applications
- Currently Located: Kunming, Yunnan, China
Designed to withstand rigorous mining, infrastructure, and heavy construction projects, this SK480 combines durability with operational efficiency. Transport dimensions of 12,080mm × 3,580mm × 3,800mm facilitate straightforward logistics planning for your next project deployment.
| Specifications | Value |
|---|---|
| No. | 1012469 |
| Tonnage (tons) | 48 |
| Bucket capacity (m³) | 2.3 |
| Boom length (mm) | 7000 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Total transport length (mm) | 12080 |
| Total transport width (mm) | 3580 |
| Total transport height (mm) | 3800 |
| Counterweight ground clearance (mm) | 1340 |
| Minimum ground clearance (mm) | 510 |
| Back end turning radius (mm) | 3670 |
| Onboard width (mm) | 3000 |
| Total track length (mm) | 5450 |
| Track plate width (mm) | 600 |
| Maximum digging radius (mm) | 11700 |
| Maximum digging depth (mm) | 7370 |
| Maximum excavation height (mm) | 11160 |
| Maximum vertical digging depth (mm) | 6680 |
| Maximum excavation radius of stop surface (mm) | 11540 |
