Product Description
Available now in Guangdong, Shenzhen—this 2018 Kobelco SK495D delivers 49-ton performance without the wait. Skip factory lead times and put this proven excavator to work immediately on your next large-scale earthmoving or demolition project. Powered by a robust Hino P11C engine generating 257 kW at 1850 rpm, this machine combines Japanese engineering precision with the capacity to handle demanding applications across construction, mining, and infrastructure development.
Built for serious productivity, this unit offers:
- Maximum digging reach of 11,770 mm and depth to 7,360 mm
- Powerful 266 kN bucket digging force with 2.3 m³ capacity
- Dual variable displacement pumps (2 × 370 L/min) for responsive hydraulics
- 52,700 kg operating weight with 70% gradeability for challenging terrain
- Water-cooled, turbocharged 10.52L engine with intercooling
- 650L fuel tank for extended operating shifts
Fast deployment to your site means revenue starts sooner. Contact Fair Trade Machinery today to inspect this ready-to-ship SK495D and accelerate your project timeline.
| Specifications | Value |
|---|---|
| No. | 1017922 |
| Tonnage (tons) | 49 |
| Working weight (kg) | 52700 |
| Bucket capacity (m³) | 2.3 |
| Boom length (mm) | 7000 |
| Rod length (mm) | 3000 |
| Country of origin | Chengdu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Hino P11C |
| Rated power (kw/rpm) | 257/1850 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 122 x 150 |
| Maximum torque (N.m) | 1400 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 10.52 |
| Working form | Direct injection, water-cooled, four-stroke, turbocharged, built-in intercooling |
| Rotation speed (rpm) | 7.8 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 266 |
| Rod digging force (kN) | 223 |
| Maximum tractive force (kN) | 417 |
| Travel speed (km/h) | 5.4/3.4 |
| Maximum flow of main pump (l/min) | 2 x 370 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Control Hydraulic Circuit (Mpa) | 5 |
| Main pump type | Dual variable displacement axial piston pump |
| Working Hydraulic Circuit (Mpa) | 31.4 |
| Fuel Tank (L) | 650 |
| Hydraulic Tank (L) | 300 |
| Engine Oil changes (L) | 50 |
| Coolant (L) | 41 |
| Hydraulic System (L) | 555 |
| Total transport length (mm) | 12080 |
| Total transport width (mm) | 3570 |
| Total transport height (mm) | 3800 |
| Minimum ground clearance (mm) | 510 |
| Minimum turning radius of front working device (mm) | 5270 |
| Back end turning radius (mm) | 3670 |
| Total track length (mm) | 5460 |
| Total track width (mm) | 3130 |
| Maximum height at minimum turning radius (mm) | 9003 |
| Maximum digging radius (mm) | 11770 |
| Maximum digging depth (mm) | 7360 |
| Maximum excavation height (mm) | 11160 |
| Maximum unloading height (mm) | 7720 |
| Maximum vertical digging depth (mm) | 6680 |
| Maximum excavation radius of stop surface (mm) | 11540 |
