Product Description
Built for relentless performance, this 2018 Kobelco SK495D stands as a proven workhorse in the 49-ton excavator class. Powered by a robust Hino P11C engine delivering 257kW at 1850rpm, this machine combines 10.52L of displacement with advanced water-cooled, turbocharged technology to tackle the toughest jobsites. With over five years of proven service, its durability speaks volumes about Kobelco's engineering excellence.
- Operating weight: 52,700kg with 2.3m³ bucket capacity for maximum productivity
- Impressive reach: 11,770mm digging radius and 7,360mm maximum depth
- Powerful hydraulics: dual 370 L/min variable pumps generating 266kN bucket force
- Superior mobility: 70% climbing ability and 5.4km/h travel speed
- Generous fuel capacity: 650L tank minimizes downtime on extended shifts
- Currently located in Shanghai, ready for immediate deployment
Designed to withstand demanding conditions, this SK495D represents reliable heavy-duty excavation capability backed by Kobelco's reputation for longevity. A dependable choice for contractors requiring consistent performance and proven reliability.
| Specifications | Value |
|---|---|
| No. | 1019528 |
| Tonnage (tons) | 49 |
| Working weight (kg) | 52700 |
| Bucket capacity (m³) | 2.3 |
| Boom length (mm) | 7000 |
| Rod length (mm) | 3000 |
| Country of origin | Chengdu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Hino P11C |
| Rated power (kw/rpm) | 257/1850 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 122 x 150 |
| Maximum torque (N.m) | 1400 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 10.52 |
| Working form | Direct injection, water-cooled, four-stroke, turbocharged, built-in intercooling |
| Rotation speed (rpm) | 7.8 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 266 |
| Rod digging force (kN) | 223 |
| Maximum tractive force (kN) | 417 |
| Travel speed (km/h) | 5.4/3.4 |
| Maximum flow of main pump (l/min) | 2 x 370 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Control Hydraulic Circuit (Mpa) | 5 |
| Main pump type | Dual variable displacement axial piston pump |
| Working Hydraulic Circuit (Mpa) | 31.4 |
| Fuel Tank (L) | 650 |
| Hydraulic Tank (L) | 300 |
| Engine Oil changes (L) | 50 |
| Coolant (L) | 41 |
| Hydraulic System (L) | 555 |
| Total transport length (mm) | 12080 |
| Total transport width (mm) | 3570 |
| Total transport height (mm) | 3800 |
| Minimum ground clearance (mm) | 510 |
| Minimum turning radius of front working device (mm) | 5270 |
| Back end turning radius (mm) | 3670 |
| Total track length (mm) | 5460 |
| Total track width (mm) | 3130 |
| Maximum height at minimum turning radius (mm) | 9003 |
| Maximum digging radius (mm) | 11770 |
| Maximum digging depth (mm) | 7360 |
| Maximum excavation height (mm) | 11160 |
| Maximum unloading height (mm) | 7720 |
| Maximum vertical digging depth (mm) | 6680 |
| Maximum excavation radius of stop surface (mm) | 11540 |
