Product Description
Engineered for precision and operator control, this 2018 Kobelco SK495D delivers 49-ton performance with exceptional stability across demanding jobsites. Powered by a Hino P11C engine producing 257 kW at 1850 rpm, this excavator combines robust digging force (266 kN bucket, 223 kN arm) with refined hydraulics for smooth, responsive operation. Operators benefit from superior visibility and ergonomic cabin design typical of Kobelco's joint-venture manufacturing standards, reducing fatigue during extended shifts.
- Working Weight: 52,700 kg with 2.3 m³ bucket capacity
- Reach & Depth: 11,770 mm maximum digging radius, 7,360 mm depth
- Hydraulic System: Dual variable piston pumps (2 × 370 L/min) at 31.4 MPa
- Mobility: 7.8 rpm rotation speed, 70% grading ability, 5.4 km/h travel speed
- Cooling: Water-cooled turbocharged system with intercooling for consistent performance
- Location: Shandong, China — ready for global shipment
Built for contractors demanding reliability and control in heavy excavation, demolition, and large-scale earthmoving projects.
| Specifications | Value |
|---|---|
| No. | 1027916 |
| Tonnage (tons) | 49 |
| Working weight (kg) | 52700 |
| Bucket capacity (m³) | 2.3 |
| Boom length (mm) | 7000 |
| Rod length (mm) | 3000 |
| Country of origin | Chengdu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Hino P11C |
| Rated power (kw/rpm) | 257/1850 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 122 x 150 |
| Maximum torque (N.m) | 1400 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 10.52 |
| Working form | Direct injection, water-cooled, four-stroke, turbocharged, built-in intercooling |
| Rotation speed (rpm) | 7.8 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 266 |
| Rod digging force (kN) | 223 |
| Maximum tractive force (kN) | 417 |
| Travel speed (km/h) | 5.4/3.4 |
| Maximum flow of main pump (l/min) | 2 x 370 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Control Hydraulic Circuit (Mpa) | 5 |
| Main pump type | Dual variable displacement axial piston pump |
| Working Hydraulic Circuit (Mpa) | 31.4 |
| Fuel Tank (L) | 650 |
| Hydraulic Tank (L) | 300 |
| Engine Oil changes (L) | 50 |
| Coolant (L) | 41 |
| Hydraulic System (L) | 555 |
| Total transport length (mm) | 12080 |
| Total transport width (mm) | 3570 |
| Total transport height (mm) | 3800 |
| Minimum ground clearance (mm) | 510 |
| Minimum turning radius of front working device (mm) | 5270 |
| Back end turning radius (mm) | 3670 |
| Total track length (mm) | 5460 |
| Total track width (mm) | 3130 |
| Maximum height at minimum turning radius (mm) | 9003 |
| Maximum digging radius (mm) | 11770 |
| Maximum digging depth (mm) | 7360 |
| Maximum excavation height (mm) | 11160 |
| Maximum unloading height (mm) | 7720 |
| Maximum vertical digging depth (mm) | 6680 |
| Maximum excavation radius of stop surface (mm) | 11540 |
