2018 Kobelco SK495D

1/5
Buy Kobelco SK495D Used Excavator / 1
Buy Kobelco SK495D Used Excavator / 2
Buy Kobelco SK495D Used Excavator / 3
Buy Kobelco SK495D Used Excavator / 4
Buy Kobelco SK495D Used Excavator / 5

Product Description

Built in 2018 and currently located in Luzhou, Sichuan, this Kobelco SK495D delivers 49-ton class performance with proven reliability backed by Japan's joint-venture manufacturing standards. Powered by a Hino P11C engine producing 257 kW at 1850 rpm, this excavator combines a 2.3 m³ bucket capacity with an impressive 11,770 mm maximum digging radius and 7,360 mm digging depth for demanding earthmoving applications.

Kobelco's reputation in the used equipment market stems from exceptional parts availability and strong resale value retention. With dual 370 l/min variable displacement pumps and 266 kN bucket digging force, this SK495D maintains the operational efficiency that makes Kobelco machines a safe investment. The water-cooled, turbocharged P11C engine with intercooling technology ensures consistent performance across heavy-duty cycles, while the 70% climbing ability and 5.4 km/h travel speed provide excellent jobsite mobility.

Specifications include:

  • Operating weight: 52,700 kg with 7,000 mm boom and 3,000 mm arm
  • Hydraulic system: 555 L capacity, 31.4 MPa working pressure
  • Fuel capacity: 650 L for extended operation
  • Transport dimensions: 12,080 mm × 3,570 mm × 3,800 mm
SpecificationsValue
No.1043953
Tonnage (tons)49
Working weight (kg)52700
Bucket capacity (m³)2.3
Boom length (mm)7000
Rod length (mm)3000
Country of originChengdu
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeHino P11C
Rated power (kw/rpm)257/1850
Cooling modewater-cooling
Cylinder diameter × stroke (mm)122 x 150
Maximum torque (N.m)1400
Number of cylinders (PCS)6
Displacement (L)10.52
Working formDirect injection, water-cooled, four-stroke, turbocharged, built-in intercooling
Rotation speed (rpm)7.8
Climbing ability (%)70% (35°)
Bucket digging force (kN)266
Rod digging force (kN)223
Maximum tractive force (kN)417
Travel speed (km/h)5.4/3.4
Maximum flow of main pump (l/min)2 x 370
Traveling Hydraulic Circuit (Mpa)34.3
Rotary Hydraulic Circuit (Mpa)25
Control Hydraulic Circuit (Mpa)5
Main pump typeDual variable displacement axial piston pump
Working Hydraulic Circuit (Mpa)31.4
Fuel Tank (L)650
Hydraulic Tank (L)300
Engine Oil changes (L)50
Coolant (L)41
Hydraulic System (L)555
Total transport length (mm)12080
Total transport width (mm)3570
Total transport height (mm)3800
Minimum ground clearance (mm)510
Minimum turning radius of front working device (mm)5270
Back end turning radius (mm)3670
Total track length (mm)5460
Total track width (mm)3130
Maximum height at minimum turning radius (mm)9003
Maximum digging radius (mm)11770
Maximum digging depth (mm)7360
Maximum excavation height (mm)11160
Maximum unloading height (mm)7720
Maximum vertical digging depth (mm)6680
Maximum excavation radius of stop surface (mm)11540
see more

Overview

No.1043953

Brand Name:

Kobelco

Model Number:

SK495D

Year:

2018

Location:

Sichuan China

Pub Date
