Product Description
Proven performance meets smart economics with this 2016 Kobelco SK60-8 compact excavator, currently located in Hangzhou, Zhejiang. Powered by a reliable Yanmar 4TNV94L engine delivering 35.5kW at 2400rpm, this 6-ton machine offers exceptional value for contractors seeking dependable performance without the premium price tag of new equipment. Engineered in Chengdu with joint venture quality standards, it combines a 0.22m³ bucket capacity with impressive digging force—40.1kN bucket force and 25.2kN arm force—making it ideal for urban construction, utility work, and landscaping projects.
- Operating Weight: 5,610 kg with optimal 32.7 Kpa ground pressure
- Reach & Depth: 6,200mm max digging radius, 3,890mm digging depth
- Hydraulic System: Dual variable piston pumps (2×57.1 L/min) for responsive control
- Mobility: 58% climbing ability, 4.2/2.5 km/h travel speeds
- Compact Dimensions: 5,850mm transport length, 1,960mm width for tight access
Acquire proven Japanese engineering at a fraction of replacement cost. This water-cooled, direct-injection machine represents substantial savings while
| Specifications | Value |
|---|---|
| No. | 1050177 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5610 |
| Bucket capacity (m³) | 0.22 |
| Rod length (mm) | 1660 |
| Country of origin | Chengdu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 35.5/2400 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 21.7/1440 |
| Number of cylinders (PCS) | 4 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 32.7 |
| Rotation speed (rpm) | 8.9 |
| Climbing ability (%) | 58% (30 degrees) |
| Bucket digging force (kN) | 40.1 |
| Rod digging force (kN) | 25.2 |
| Travel speed (km/h) | 4.2/2.5 |
| Main overflow set pressure (Mpa) | 23 |
| Maximum flow of main pump (l/min) | 2*57.1 |
| Main pump type | Variable piston pump *2+ gear pump *2 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 1960 |
| Total transport height (mm) | 2550 |
| Full cab height (mm) | 2550 |
| Track plate width (mm) | 400 |
| Maximum digging radius (mm) | 6200 |
| Maximum digging depth (mm) | 3890 |
| Maximum excavation height (mm) | 5730 |
| Maximum unloading height (mm) | 4200 |
| Bulldozer lift or depth (mm) | 470/380 |
| Dodging plate width × height (mm) | 1960*345 |
