Product Description
This 2014 Kobelco SK75SR-3 midi excavator offers proven performance for contractors seeking reliable equipment without significant capital investment. Operating weight approximately 7.5 tonnes with a Yanmar diesel engine delivering robust power for general earthmoving, trenching, and utility work.
Currently located in Jiangsu Province, China. The machine has been actively used in commercial operations and shows corresponding wear consistent with its service history. Mechanically functional and ready for immediate deployment.
- Year: 2014
- Model: Kobelco SK75SR-3
- Operating Weight: ~7,500 kg
- Engine: Yanmar 4TNV98 diesel
- Bucket Capacity: 0.28 m³ (standard)
- Max Digging Depth: ~4,300 mm
- Location: Jiangsu, China
- Condition: Used, operational
Suitable for small to medium-scale construction, landscaping, and municipal projects. Inspection recommended prior to purchase. Price reflects current working condition.
| Specifications | Value |
|---|---|
| No. | 1083657 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7000(approx) |
| Country of origin | Chengdu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU AU4LE2X |
| Rated power (kw/rpm) | 41/2200 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 85 x 96 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.179 |
| Rotary hydraulic motor type | Axial piston motor |
| Traveling Hydraulic Circuit (Mpa) | 27.5 |
| Rotary Hydraulic Circuit (Mpa) | 14.5 |
| Control Hydraulic Circuit (Mpa) | 3.5 |
| Main pump type | Double variable displacement axial piston pump + pilot gear pump |
| Working Hydraulic Circuit (Mpa) | 29.4 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 72 |
| Engine Oil changes (L) | 11 |
| Coolant (L) | 8.5 |
| Hydraulic System (L) | 120 |
| Total transport height (mm) | 2630 |
| Full cab height (mm) | 2630 |
| Minimum turning radius of front working device (mm) | 1760 |
| Back end turning radius (mm) | 1290 |
| Maximum digging radius (mm) | 6460 |
| Maximum digging depth (mm) | 4160 |
| Maximum excavation height (mm) | 7390 |
| Maximum unloading height (mm) | 5330 |
| Maximum vertical digging depth (mm) | 3450 |
| Maximum excavation radius of stop surface (mm) | 6300 |
| Maximum effective digging depth (mm) | 3800 |
| Travel speed (km/h) | 2.8/5.3 |
