Product Description
This 2014 Kobelco SK75 midi excavator offers reliable performance for contractors and demolition professionals seeking value in the used equipment market. Currently located in Zhejiang, China, this machine represents an economical entry point into the proven SK75 platform.
The Kobelco SK75 is recognized for its 7.5-tonne operating weight and compact footprint, making it suitable for urban construction, utility work, and landscaping applications. This 2014 model year unit comes from Kobelco's well-established midi excavator line, known for balanced power and fuel efficiency.
- Year of Manufacture: 2014
- Model: Kobelco SK75
- Current Location: Zhejiang Province, China
- Competitive pricing for budget-conscious operations
- Suitable for export or domestic deployment
Contact our team for current condition assessment, available documentation, and shipping solutions to your location.
| Specifications | Value |
|---|---|
| No. | 1096247 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7000(approx) |
| Country of origin | Chengdu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU AU4LE2X |
| Rated power (kw/rpm) | 41/2200 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 85 x 96 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.179 |
| Rotary hydraulic motor type | Axial piston motor |
| Traveling Hydraulic Circuit (Mpa) | 27.5 |
| Rotary Hydraulic Circuit (Mpa) | 14.5 |
| Control Hydraulic Circuit (Mpa) | 3.5 |
| Main pump type | Double variable displacement axial piston pump + pilot gear pump |
| Working Hydraulic Circuit (Mpa) | 29.4 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 72 |
| Engine Oil changes (L) | 11 |
| Coolant (L) | 8.5 |
| Hydraulic System (L) | 120 |
| Total transport height (mm) | 2630 |
| Full cab height (mm) | 2630 |
| Minimum turning radius of front working device (mm) | 1760 |
| Back end turning radius (mm) | 1290 |
| Maximum digging radius (mm) | 6460 |
| Maximum digging depth (mm) | 4160 |
| Maximum excavation height (mm) | 7390 |
| Maximum unloading height (mm) | 5330 |
| Maximum vertical digging depth (mm) | 3450 |
| Maximum excavation radius of stop surface (mm) | 6300 |
| Maximum effective digging depth (mm) | 3800 |
| Travel speed (km/h) | 2.8/5.3 |
