2015 Kobelco SK75

1/6
Buy Kobelco SK75 Used Excavator / 1
Buy Kobelco SK75 Used Excavator / 2
Buy Kobelco SK75 Used Excavator / 3
Buy Kobelco SK75 Used Excavator / 4
Buy Kobelco SK75 Used Excavator / 5
Buy Kobelco SK75 Used Excavator / 6

Product Description

This 2015 Kobelco SK75 compact excavator is now available from our Sichuan, China location. With approximately 8-9 years of field operation, this mid-sized crawler excavator offers proven reliability from one of Japan's leading construction equipment manufacturers. The SK75 series is recognized for its balanced performance in urban construction, utility work, and light demolition applications.

Key features of this unit include:

  • Kobelco's fuel-efficient engine technology for reduced operating costs
  • Compact footprint suitable for confined job sites
  • Robust undercarriage designed for durability
  • Versatile 7.5-ton class performance
  • Well-maintained condition with documented service history

This machine represents an economical entry point for contractors seeking dependable Japanese engineering at competitive pricing. Ideal for rental fleets, municipal projects, or growing construction businesses. Full inspection reports available upon request. Export documentation and loading assistance can be arranged.

SpecificationsValue
No.1088627
Tonnage (tons)7
Working weight (kg)7000(approx)
Country of originChengdu
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeISUZU AU4LE2X
Rated power (kw/rpm)41/2200
Cooling modewater-cooling
Cylinder diameter × stroke (mm)85 x 96
Number of cylinders (PCS)4
Displacement (L)2.179
Rotary hydraulic motor typeAxial piston motor
Traveling Hydraulic Circuit (Mpa)27.5
Rotary Hydraulic Circuit (Mpa)14.5
Control Hydraulic Circuit (Mpa)3.5
Main pump typeDouble variable displacement axial piston pump + pilot gear pump
Working Hydraulic Circuit (Mpa)29.4
Fuel Tank (L)120
Hydraulic Tank (L)72
Engine Oil changes (L)11
Coolant (L)8.5
Hydraulic System (L)120
Total transport height (mm)2630
Full cab height (mm)2630
Minimum turning radius of front working device (mm)1760
Back end turning radius (mm)1290
Maximum digging radius (mm)6460
Maximum digging depth (mm)4160
Maximum excavation height (mm)7390
Maximum unloading height (mm)5330
Maximum vertical digging depth (mm)3450
Maximum excavation radius of stop surface (mm)6300
Maximum effective digging depth (mm)3800
Travel speed (km/h)2.8/5.3
see more

Overview

No.1088627

Brand Name:

Kobelco

Model Number:

SK75

Year:

2015

Location:

Sichuan China

Pub Date
