Product Description
With a working weight of approximately 7,000 kg and powered by a reliable ISUZU AU4LE2X engine, this 2018 Kobelco SK75 excavator is an ideal addition to any busy contractor's fleet. Located in 湖南, it offers robust performance with its 41 kW rated power at 2200 rpm, ensuring efficient operation on various job sites. Featuring a backhoe bucket and a water-cooled engine, this model is designed for durability and efficiency. The hydraulic system, equipped with a double variable displacement axial piston pump, provides precise control and high productivity. Ideal as a backup or to expand your fleet, the SK75 boasts a maximum digging depth of 4160 mm and a travel speed of 2.8/5.3 km/h, making it versatile for multiple applications. Trust the reliability and performance of this Kobelco unit to enhance your operational capacity.
| Specifications | Value |
|---|---|
| No. | 1029490 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7000(approx) |
| Country of origin | Chengdu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU AU4LE2X |
| Rated power (kw/rpm) | 41/2200 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 85 x 96 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.179 |
| Rotary hydraulic motor type | Axial piston motor |
| Traveling Hydraulic Circuit (Mpa) | 27.5 |
| Rotary Hydraulic Circuit (Mpa) | 14.5 |
| Control Hydraulic Circuit (Mpa) | 3.5 |
| Main pump type | Double variable displacement axial piston pump + pilot gear pump |
| Working Hydraulic Circuit (Mpa) | 29.4 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 72 |
| Engine Oil changes (L) | 11 |
| Coolant (L) | 8.5 |
| Hydraulic System (L) | 120 |
| Total transport height (mm) | 2630 |
| Full cab height (mm) | 2630 |
| Minimum turning radius of front working device (mm) | 1760 |
| Back end turning radius (mm) | 1290 |
| Maximum digging radius (mm) | 6460 |
| Maximum digging depth (mm) | 4160 |
| Maximum excavation height (mm) | 7390 |
| Maximum unloading height (mm) | 5330 |
| Maximum vertical digging depth (mm) | 3450 |
| Maximum excavation radius of stop surface (mm) | 6300 |
| Maximum effective digging depth (mm) | 3800 |
| Travel speed (km/h) | 2.8/5.3 |
