2018 Komatsu PC110-7

1/5
Buy Komatsu PC110-7 Used Excavator / 1
Buy Komatsu PC110-7 Used Excavator / 2
Buy Komatsu PC110-7 Used Excavator / 3
Buy Komatsu PC110-7 Used Excavator / 4
Buy Komatsu PC110-7 Used Excavator / 5

Product Description

Discover the reliability and efficiency of the 2018 Komatsu PC110-7, a robust excavator designed for a variety of heavy-duty applications. Located in Sichuan, China, this machine is available at an attractive price of 120,000 RMB, making it a cost-effective solution for your construction or excavation needs. The PC110-7 model is known for its durability and performance, ensuring that you can tackle demanding tasks with ease. Ideal for both small and large projects, this excavator offers a blend of power and precision, backed by Komatsu's reputation for quality and innovation.

  • Year: 2018
  • Brand: Komatsu
  • Model: PC110-7
  • Price: 120,000 RMB
  • Location: Sichuan, China
SpecificationsValue
No.1092524
Tonnage (tons)11
Working weight (kg)10980
Bucket capacity (m³)0.48
Boom length (mm)4260
Rod length (mm)2260
Country of originJining, Shandong Province
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeKomatsu SAA4D95LE-3
Rated power (kw/rpm)65/2200
Cooling modewater-cooling
Cylinder diameter × stroke (mm)95 x 115
Displacement (L)3.26
Working form4 stroke, after cooling, direct injection; Comply with 2001 EPA/EU/ Japan Level 2 emission standards.
Ground specific pressure (Kpa)0.37
Rotation speed (rpm)11
Climbing ability (%)70/30 °
Bucket digging force (kN)86
Rod digging force (kN)56
Travel speed (km/h)2.7-5.5
Rotary hydraulic motor typeAxial piston motor ×1(rotary holding valve)
Type of walking hydraulic motorAxial piston motor ×2(with parking brake)
Maximum flow of main pump (l/min)226L/min
Traveling Hydraulic Circuit (Mpa)355
Rotary Hydraulic Circuit (Mpa)295
Control Hydraulic Circuit (Mpa)325
Hydraulic crushing pipeline is standardno
Bucket cylinders - Number × diameter × stroke (mm)104 x 885 x 60
Bucket rod cylinders - Number × diameter × stroke (mm)133 * 1005 * 75
Boom cylinders - Number × diameter × stroke (mm)110 * 980 * 65
Fuel Tank (L)247
Hydraulic Tank (L)90
Engine Oil changes (L)11
Coolant (L)13.4
Total transport length (mm)7170
Total transport width (mm)2490
Total transport height (mm)2810
Full cab height (mm)2810
Counterweight ground clearance (mm)855
Minimum ground clearance (mm)400
Back end turning radius (mm)2110
Total track length (mm)3435
Track gauge (mm)1990
Track plate width (mm)500
Total track width (mm)2490
Track ground length (mm)2705
Maximum digging radius (mm)7730
Maximum digging depth (mm)5060
Maximum excavation height (mm)7910
Maximum unloading height (mm)5650
Maximum vertical digging depth (mm)4570
Bulldozer lift or depth (mm)No bulldozer
Maximum excavation radius of stop surface (mm)7600
Maximum effective digging depth (mm)4730
see more

Overview

No.1092524

Brand Name:

Komatsu

Model Number:

PC110-7

Year:

2018

Location:

Sichuan China

Pub Date
