Product Description
Engineered with Komatsu's proven SAA4D95LE-3 turbocharged diesel engine, this PC130-7 delivers 66 kW at 2200 rpm through a 3.26L displacement with intercooled direct injection technology. Hydraulic performance centers on a 226 l/min main pump feeding dedicated circuits: 32 MPa working pressure, 35 MPa travel, and 29 MPa rotation systems—precision-tuned for responsive control across all functions. Bucket digging force reaches 93.2 kN while rod digging force achieves 61.8 kN, backed by a 0.53 m³ capacity bucket and 2100 mm rod configuration.
Built on joint venture manufacturing standards, this 13-ton excavator combines a 12,600 kg working weight with operational intelligence. Water-cooled efficiency maintains thermal stability during extended cycles. Dimensional reach includes 8290 mm maximum digging radius, 5520 mm digging depth, and 8610 mm excavation height. The 2880 mm track ground length and 500 mm-wide plates distribute 38 kPa ground pressure while maintaining 70% grading capability. Currently located in Luzhou, Sichuan, this machine represents Komatsu's commitment to hydraulic refinement and mechanical durability in the mid-size excavator segment.
| Specifications | Value |
|---|---|
| No. | 1024486 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12600 |
| Bucket capacity (m³) | 0.53 |
| Rod length (mm) | 2100 |
| Country of origin | Jining, Shandong Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu SAA4D95LE-3 |
| Rated power (kw/rpm) | 66/2200 |
| Cooling mode | water-cooling |
| Displacement (L) | 3.26 |
| Working form | Direct injection, turbocharged, intercooled diesel engine |
| Ground specific pressure (Kpa) | 38 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70/30 ° |
| Bucket digging force (kN) | 93.2 |
| Rod digging force (kN) | 61.8 |
| Travel speed (km/h) | 2.7-5.5 |
| Maximum flow of main pump (l/min) | 226 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 29 |
| Control Hydraulic Circuit (Mpa) | 30 |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 32 |
| Fuel Tank (L) | 247 |
| Hydraulic Tank (L) | 90 |
| Engine Oil changes (L) | 11 |
| Coolant (L) | 13.4 |
| Total transport length (mm) | 7599 |
| Total transport height (mm) | 2175 |
| Full cab height (mm) | 2175 |
| Counterweight ground clearance (mm) | 855 |
| Minimum ground clearance (mm) | 400 |
| Back end turning radius (mm) | 2110 |
| Total track length (mm) | 3610 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2880 |
| Maximum digging radius (mm) | 8290 |
| Maximum digging depth (mm) | 5520 |
| Maximum excavation height (mm) | 8610 |
| Maximum unloading height (mm) | 6170 |
| Maximum vertical digging depth (mm) | 4940 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 8170 |
| Maximum effective digging depth (mm) | 5315 |
