2015 Komatsu PC130-7

1/9
Buy Komatsu PC130-7 Used Excavator / 1
Buy Komatsu PC130-7 Used Excavator / 2
Buy Komatsu PC130-7 Used Excavator / 3
Buy Komatsu PC130-7 Used Excavator / 4
Buy Komatsu PC130-7 Used Excavator / 5
Buy Komatsu PC130-7 Used Excavator / 6
Buy Komatsu PC130-7 Used Excavator / 7
Buy Komatsu PC130-7 Used Excavator / 8
Buy Komatsu PC130-7 Used Excavator / 9

Product Description

This 2015 Komatsu PC130-7 hydraulic excavator represents an exceptional opportunity for operators seeking reliable mid-size performance. Currently located in Hebei, China, this direct injection model has been carefully stored for several years and demonstrates outstanding preservation. The undercarriage retains approximately 90% of its original condition, showing minimal wear and excellent structural integrity.

Key operational highlights include:

  • Responsive hydraulic system with smooth, coordinated movement and strong digging force
  • Well-maintained major components with no oil leaks or seepage
  • Clean, dry engine, hydraulic pump, and transmission assemblies
  • Preserved original chassis components in near-excellent condition

The PC130-7's proven reliability and fuel-efficient direct injection system make it suitable for construction, excavation, and material handling applications. This unit's exceptional preservation during storage ensures immediate operational readiness with minimal reconditioning required.

SpecificationsValue
No.1089540
Tonnage (tons)13
Working weight (kg)12600
Bucket capacity (m³)0.53
Rod length (mm)2100
Country of originJining, Shandong Province
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeKomatsu SAA4D95LE-3
Rated power (kw/rpm)66/2200
Cooling modewater-cooling
Displacement (L)3.26
Working formDirect injection, turbocharged, intercooled diesel engine
Ground specific pressure (Kpa)38
Rotation speed (rpm)11
Climbing ability (%)70/30 °
Bucket digging force (kN)93.2
Rod digging force (kN)61.8
Travel speed (km/h)2.7-5.5
Maximum flow of main pump (l/min)226
Traveling Hydraulic Circuit (Mpa)35
Rotary Hydraulic Circuit (Mpa)29
Control Hydraulic Circuit (Mpa)30
Hydraulic crushing pipeline is standardno
Working Hydraulic Circuit (Mpa)32
Fuel Tank (L)247
Hydraulic Tank (L)90
Engine Oil changes (L)11
Coolant (L)13.4
Total transport length (mm)7599
Total transport height (mm)2175
Full cab height (mm)2175
Counterweight ground clearance (mm)855
Minimum ground clearance (mm)400
Back end turning radius (mm)2110
Total track length (mm)3610
Track gauge (mm)1990
Track plate width (mm)500
Track ground length (mm)2880
Maximum digging radius (mm)8290
Maximum digging depth (mm)5520
Maximum excavation height (mm)8610
Maximum unloading height (mm)6170
Maximum vertical digging depth (mm)4940
Bulldozer lift or depth (mm)No bulldozer
Maximum excavation radius of stop surface (mm)8170
Maximum effective digging depth (mm)5315
see more

Overview

No.1089540

Brand Name:

Komatsu

Model Number:

PC130-7

Year:

2015

Location:

Hebei China
