Product Description
Built to endure the toughest jobsites, this 2016 Komatsu PC130-8 stands as a proven workhorse in the 13-ton excavator class. Operating from Guangdong Shenzhen, this Japanese-engineered machine demonstrates the legendary durability that has made Komatsu a trusted name in construction equipment worldwide. Powered by the reliable Komatsu SAA4D95LE-5 engine delivering 68kW at 2200rpm, this direct injection, turbocharged, and intercooled diesel unit provides consistent performance through demanding applications.
With a 0.5m³ bucket capacity and impressive reach specifications—including 5520mm maximum digging depth and 8170mm excavation radius—this PC130-8 tackles medium-duty excavation, trenching, and material handling with proven efficiency. The water-cooled 4-cylinder engine, combined with a 242 L/min hydraulic flow rate, ensures responsive control and productivity. Years of field operation have validated its robust construction, from the reinforced undercarriage with 2880mm track ground length to the precision-engineered boom and arm assembly.
Key specifications include:
- Working weight: 12,560kg with optimal 32.6kPa ground pressure
- Compact transport dimensions: 7590mm length × 2590mm width × 2875m
| Specifications | Value |
|---|---|
| No. | 993475 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12560 |
| Bucket capacity (m³) | 0.5 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2500 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu SAA4D95LE-5 |
| Rated power (kw/rpm) | 68/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.3 |
| Working form | Direct injection, turbocharged, intercooled diesel engine |
| Ground specific pressure (Kpa) | 32.6 |
| Rotation speed (rpm) | 11 |
| Travel speed (km/h) | 5.5 |
| Maximum flow of main pump (l/min) | 242 |
| Hydraulic crushing pipeline is standard | no |
| Fuel Tank (L) | 247 |
| Hydraulic Tank (L) | 90 |
| Engine Oil changes (L) | 11.5 |
| Coolant (L) | 13.9 |
| Total transport length (mm) | 7590 |
| Total transport width (mm) | 2590 |
| Total transport height (mm) | 2875 |
| Full cab height (mm) | 2855 |
| Counterweight ground clearance (mm) | 895 |
| Minimum ground clearance (mm) | 400 |
| Back end turning radius (mm) | 2190 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2590 |
| Track ground length (mm) | 2880 |
| Maximum digging depth (mm) | 5520 |
| Maximum excavation height (mm) | 8650 |
| Maximum unloading height (mm) | 6210 |
| Maximum vertical digging depth (mm) | 4980 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 8170 |
