Product Description
Powered by the Komatsu SAA4D95LE-5 turbocharged and intercooled diesel engine, this 2018 PC130-8 delivers 68 kW of rated power at 2200 rpm through a proven 3.3L displacement configuration. Engineering excellence defines the 13-ton class with a maximum main pump flow of 242 L/min, ensuring responsive hydraulic performance across all operating conditions. The water-cooled, direct-injection powerplant provides fuel efficiency while maintaining consistent performance throughout demanding job cycles.
With a maximum digging depth of 5,520 mm and excavation radius of 8,170 mm, this machine covers substantial work areas from a single position. The 4,600 mm boom and 2,500 mm arm geometry optimize breakout force and cycle times. Operating specifications include 11 rpm rotation speed and 5.5 km/h travel speed, supported by a 2,880 mm track ground length that distributes the 12,560 kg working weight across a ground pressure of just 32.6 kPa.
Currently located in Ningde, Fujian, this joint-venture manufactured unit represents Komatsu's commitment to durability and operational precision in the medium excavator segment.
| Specifications | Value |
|---|---|
| No. | 1030960 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12560 |
| Bucket capacity (m³) | 0.5 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2500 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu SAA4D95LE-5 |
| Rated power (kw/rpm) | 68/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.3 |
| Working form | Direct injection, turbocharged, intercooled diesel engine |
| Ground specific pressure (Kpa) | 32.6 |
| Rotation speed (rpm) | 11 |
| Travel speed (km/h) | 5.5 |
| Maximum flow of main pump (l/min) | 242 |
| Hydraulic crushing pipeline is standard | no |
| Fuel Tank (L) | 247 |
| Hydraulic Tank (L) | 90 |
| Engine Oil changes (L) | 11.5 |
| Coolant (L) | 13.9 |
| Total transport length (mm) | 7590 |
| Total transport width (mm) | 2590 |
| Total transport height (mm) | 2875 |
| Full cab height (mm) | 2855 |
| Counterweight ground clearance (mm) | 895 |
| Minimum ground clearance (mm) | 400 |
| Back end turning radius (mm) | 2190 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2590 |
| Track ground length (mm) | 2880 |
| Maximum digging depth (mm) | 5520 |
| Maximum excavation height (mm) | 8650 |
| Maximum unloading height (mm) | 6210 |
| Maximum vertical digging depth (mm) | 4980 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 8170 |
