Product Description
Built for contractors who can't afford downtime, this 2020 Komatsu PC130-8 delivers reliable mid-size performance straight from Hunan, China. Powered by a Komatsu SAA4D95LE-5 water-cooled, turbocharged diesel engine producing 68 kW at 2,200 RPM, it handles demanding dig cycles without hesitation — making it a smart addition to any active fleet.
At 12,560 kg operating weight with a 0.5 m³ backhoe bucket, this unit fits the gap between compact and full-size excavators. Maximum digging depth reaches 5,520 mm, with an excavation radius of 8,170 mm and unloading height of 6,210 mm — specs that cover foundation work, utility trenching, and site clearance with ease.
- Engine: Komatsu SAA4D95LE-5 | 3.3L | 4-cylinder | 68 kW @ 2,200 RPM
- Operating Weight: 12,560 kg | Bucket: 0.5 m³
- Max Digging Depth: 5,520 mm | Max Reach: 8,170 mm
- Travel Speed: 5.5 km/h | Ground Pressure: 32.6 kPa
- Fuel Tank: 247 L | Hydraulic Tank: 90 L
- Transport Dimensions: 7,590 × 2,590 × 2,875 mm
- Location: Hunan, China | Year: 2020
For contractors running multi-machine operations, having a dependable 13-ton backup unit keeps schedules intact when primary machines are down for service. This PC130-8 is job-site ready and available for immediate inspection.
| Specifications | Value |
|---|---|
| No. | 1077107 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12560 |
| Bucket capacity (m³) | 0.5 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2500 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu SAA4D95LE-5 |
| Rated power (kw/rpm) | 68/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.3 |
| Working form | Direct injection, turbocharged, intercooled diesel engine |
| Ground specific pressure (Kpa) | 32.6 |
| Rotation speed (rpm) | 11 |
| Travel speed (km/h) | 5.5 |
| Maximum flow of main pump (l/min) | 242 |
| Hydraulic crushing pipeline is standard | no |
| Fuel Tank (L) | 247 |
| Hydraulic Tank (L) | 90 |
| Engine Oil changes (L) | 11.5 |
| Coolant (L) | 13.9 |
| Total transport length (mm) | 7590 |
| Total transport width (mm) | 2590 |
| Total transport height (mm) | 2875 |
| Full cab height (mm) | 2855 |
| Counterweight ground clearance (mm) | 895 |
| Minimum ground clearance (mm) | 400 |
| Back end turning radius (mm) | 2190 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2590 |
| Track ground length (mm) | 2880 |
| Maximum digging depth (mm) | 5520 |
| Maximum excavation height (mm) | 8650 |
| Maximum unloading height (mm) | 6210 |
| Maximum vertical digging depth (mm) | 4980 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 8170 |
