Product Description
Built for precision and daily performance, this 2016 Komatsu PC150-5 delivers reliable operation across demanding job sites. With a 15-ton working weight and proven Komatsu S6D95L engine generating 74 kW at 2000 rpm, operators gain consistent hydraulic response and fuel-efficient power throughout extended shifts. Currently located in Luzhou, Sichuan, this mid-size excavator combines proven joint venture engineering with practical field capabilities.
- Operator-Centric Design: Full cabin height of 2820 mm provides excellent sight lines to the bucket and work zone, reducing blind spots during close-quarters maneuvering
- Stable Platform: 1990 mm track gauge and 2880 mm ground contact length ensure balanced weight distribution and minimal ground pressure (48.3 kPa) on soft terrain
- Responsive Handling: Compact 2445 mm rear swing radius enables tight positioning near walls and obstacles without sacrificing a maximum digging reach of 8520 mm
- Extended Uptime: 230-liter fuel capacity and 135-liter hydraulic reservoir support longer operating intervals between service stops
Proven across infrastructure, utility, and
| Specifications | Value |
|---|---|
| No. | 1030594 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 15380 |
| Bucket capacity (m³) | 0.63 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu Komatsu S6D95L |
| Rated power (kw/rpm) | 74/2000 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 48.3 |
| Travel speed (km/h) | 5.5 |
| Fuel Tank (L) | 230 |
| Hydraulic System (L) | 135 |
| Total transport length (mm) | 8520 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 8790 |
| Full cab height (mm) | 2820 |
| Counterweight ground clearance (mm) | 980 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2445 |
| Track gauge (mm) | 1990 |
| Track ground length (mm) | 2880 |
| Maximum digging depth (mm) | 5660 |
| Maximum excavation height (mm) | 8790 |
| Maximum unloading height (mm) | 6170 |
| Maximum vertical digging depth (mm) | 4890 |
| Maximum excavation radius of stop surface (mm) | 8520 |
